General
Device Type
Network surveillance camera
Audio Support
Yes
Connectivity Technology
Wired
Width
7 cm
Depth
25.93 cm
Height
7 cm
Weight
750 g
Camera
Type
Colour - Day&Night - fixed
Digital Video Format
MJPEG, H.264, H.265
Max Digital Video Resolution
2592 x 1520
Motion Detection
Yes
Minimum Illumination
0.15 lux - colour - 30 IRE ¦ 0 lux - B&W - infrared LEDs on
Infrared Distance
20 m
Digital Video Capture Resolution
1280 x 720, 720 x 480, 640 x 480, 1280 x 960, 320 x 240, 1024 x 768, 720 x 576, 1280 x 1024, 800 x 600, 1920 x 1080, 640 x 360, 2304 x 1296, 2560 x 1440, 800 x 448, 2592 x 1520
Frame Rate (max)
30 frames per second
Features
Backlight Compensation (BLC), progressive scanning, Wide Dynamic Range (WDR), Motion Detection Technology, Privacy Mask Function, Intelligent Video Analysis (IVA), tamper-detection, Lens Distortion Correction, Variable Bitrate (VBR), Constant Bitrate (CBR), Multicast Streaming, auto gain control, auto white balance, Defocus Detection, ONVIF (Profile S) support, ONVIF (Profile G) support, Samsung Super Noise Reduction (SSNR), WiseStream Smart Codec
Image Sensor
Type
4 MP CMOS 1/3"
Total Pixels
2720 x 1536
Effective Pixels
2688 x 1520
Lens Construction
Type
Board mount - motorized zoom
Optical Zoom
4.3 x
Focal Length
2.8 mm - 12 mm
Lens Iris
F/1.4 auto iris (DC)
Focus Adjustment
Automatic, manual
Horizontal Field of View (degree)
26 - 109.7
Vertical Field of View (degree)
15.2 - 60.8
Interfaces
Network Interface
Ethernet 10Base-T/100Base-TX
Network Protocols
DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ARP, ICMP, SNMP 1, SNMP 2c, SNMP 3, RTSP, RTP, HTTPS, UPnP, TLS, IPv4, IPv6, Bonjour, RTCP, PPPoE, IGMP, SSL, QOS, PIM-SM
Alarm Inputs Qty
1
Alarm Outputs Qty
1
Expansion / Connectivity
Ports
LAN/power - RJ-45 ¦ Audio line in
Supported Memory Cards
microSD Card, microSDHC Card, microSDXC Card
Miscellaneous
Compliant Standards
IK10, IP66
Colour
Dark grey
Power
Power Requirements
DC 12 V / PoE Class 3
Power Device
8 Watt
Software / System Requirements
OS Required
Microsoft Windows 7, Windows 8.1, Apple OS X 10.9 Mavericks, Apple MacOS X 10.10, Windows 10, Apple MacOS X 10.11
Environmental Parameters
Min Operating Temperature
-30 °C
Max Operating Temperature
55 °C
Relative Humidity (operating)
0 - 90%
