General
Device Type
Network surveillance camera
Audio Support
Yes
Audio Formats
G.726, ADPCM, G.711
Form Factor
Dome
Connectivity Technology
Wired
Width
13.7 cm
Depth
13.7 cm
Height
10.61 cm
Weight
710 g
Camera
Type
Colour - Day&Night - fixed - outdoor - vandal-proof
Video Format
NTSC, PAL
Digital Video Format
MJPEG, H.264, H.265
Max Digital Video Resolution
2560 x 1440
Motion Detection
Yes
Exposure Range
1/5 sec - 1/12000 sec
Minimum Illumination
0.1 lux - colour - F1.6 - shutter 1/30 sec ¦ 0 lux - B&W - infrared LEDs on
Infrared LEDs
Yes
Infrared Distance
30 m
Digital Video Capture Resolution
1280 x 720, 720 x 480, 640 x 480, 1280 x 960, 320 x 240, 800 x 600, 1920 x 1080, 640 x 360, 2560 x 1440, 800 x 448
Frame Rate (max)
30 frames per second
RAM
512 MB
Flash Memory
256 MB
Features
Backlight Compensation (BLC), white balance, image flip, image mirror, Wide Dynamic Range (WDR), Motion Detection Technology, Privacy Mask Function, Samsung Super Dynamic Range (SSDR), Lens Distortion Compensation (LDC), tamper-detection, Automatic Tracing White (ATW), Variable Bitrate (VBR), Constant Bitrate (CBR), Multicast Streaming, Defocus Detection, ONVIF (Profile S) support, ONVIF (Profile G) support, Samsung Super Noise Reduction (SSNR), WiseStream II support, IP address filtering, ICR filter, Hallway View, motion detection, Unicast Streaming, ONVIF (Profile T) support, Virtual Line detection, Gain Control
Lens Construction
Type
Motorized zoom
Optical Zoom
3.1 x
Focal Length
3.2 mm - 10 mm
Lens Iris
F/1.6-2.9 auto iris (DC)
Horizontal Field of View (degree)
30.8 - 98.6
Vertical Field of View (degree)
17.3 - 52.3
Diagonal Field of View (degree)
35.3 - 115.7
