2 EPS connectorsAll MWE Gold - V2 models come standard with 2 EPS connectors in order to ensure universal compatibility with all current gen motherboards. You never have to worry if you'll have enough connectors to use your ideal components.Quiet coolingThe MWE Gold - V2 has been upgraded with an HDB fan. This fan bearing delivers quiet and effective cooling with a long lifespan, allowing users to get the most out of their PSU for years to come. A number of additional measures has been applied to the original MWE Gold in order to reduce sound output and ripple noise for a demonstrably quieter user experience.High temperature resilienceWhile the original MWE Gold had a maximum operating temperature of only 45 degrees Celsius, the MWE Gold - V2 has improved upon this by delivering an additional 5 degrees to that limit. With this model, users will be able to push their power supply to 50 degrees Celsius safely. Such a high threshold greatly improves what's possible to accomplish with your PSU and your system in general. Overclocking and other high intensity applications become way more accessible when the system's power supply can take the heat.Full modular cablingThe full modular version of the MWE Gold - V2 comes with a set of flat black cables that can be customized to each user's individual needs. With a full modular setup, each system only needs to include the cables required for its individual components. The rest of the cables can be put aside for future upgrades and maintenance. This unused space within the chassis allows for reduced clutter and better airflow, thereby improving your system's overall cooling. Full modular cables carry an aesthetic benefit as well by reducing the amount of space needed within the case when powering the system.
Device TypePower supply - active Power Factor Correction (PFC) - internal
Specification ComplianceATX12V 2.41/ EPS12V
80 PLUS Certification80 PLUS Gold
Weight2.17 kg
LocalisationUnited Kingdom
Input VoltageAC 90-264 V
Output Voltage+3.3, +5, ±12 V
Power Capacity750 Watt
Output Current+3.3V - 20 A ¦ +5V - 20 A ¦ +12V - 62.5 A ¦ -12V - 0.3 A ¦ +5VSB - 3 A
Output connectors1 x power 24 pin ATX ¦ 1 x power 8 pin EPS12V with detachable 4 pin ATX12V section ¦ 4 x 8 pin PCI Express power with detachable 2 pin section ¦ 4 x 4 PIN internal power ¦ 12 x 15 pin Serial ATA power ¦ 1 x power 8 pin EPS12V
Modular Cable ManagementYes
Cooling System120 mm fan
Dimensions (WxDxH)15 cm x 16 cm x 8.6 cm
Manufacturer Warranty5-year warranty
Extended Specification
General
Device TypePower supply - active Power Factor Correction (PFC) - internal
Specification ComplianceATX12V 2.41/ EPS12V
PSU Form FactorATX
LocalisationUnited Kingdom
Power Device
Input VoltageAC 90-264 V
Frequency Required47 - 63 Hz
Power Output Connectors Details1 x power 24 pin ATX ¦ 1 x power 8 pin EPS12V with detachable 4 pin ATX12V section ¦ 4 x 8 pin PCI Express power with detachable 2 pin section ¦ 4 x 4 PIN internal power ¦ 12 x 15 pin Serial ATA power ¦ 1 x power 8 pin EPS12V
Output Voltage+3.3, +5, ±12 V
Power Capacity750 Watt
Output Current+3.3V - 20 A ¦ +5V - 20 A ¦ +12V - 62.5 A ¦ -12V - 0.3 A ¦ +5VSB - 3 A
Efficiency90%
Modular Cable ManagementYes
80 PLUS Certification80 PLUS Gold
Miscellaneous
MTBF100,000 hours
Cooling System120 mm fan
FeaturesOverheat protection, over current protection, over voltage protection, overpower protection, undervoltage protection, short-circuit protection, hydrodynamic bearing cooling fan, fully modular
