General
Device Type
Switch - 8 ports - L3 - Managed - stackable
Enclosure Type
Rack-mountable
Subtype
Gigabit Ethernet
Ports
8 x 10/100/1000 (PoE+) + 1 x 10/100/1000 (PoE+ input) + 2 x 1000Base-X
Power Over Ethernet (PoE)
PoE+
Performance
Switching fabric bandwidth: 24 Gbps ¦ Forwarding rate: 16.4 Mpps ¦ Buffer memory: 1.5 MB
Capacity
VLANs supported: 4094 ¦ Priority queues: 8
MAC Address Table Size
16K entries
Jumbo Frame Support
10KB
Routing Protocol
OSPF, RIP, RIP-2, IGMPv2, IGMP, VRRP, OSPFv2, PIM-SM, IGMPv3, OSPFv3, static IPv4 routing, ECMP, policy-based routing (PBR), RIPng, MLDv2, MLD, VRRPv3, CIDR, MSTP, RSTP, STP
Remote Management Protocol
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, SSH-2, CLI, SLP, SCP, SNMP 6, SSH 6, SFTP, SMTP, NTP, ICMP, DHCP, RSTP, TACACS+, RADIUS
Encryption Algorithm
DES, Triple DES, RSA, MD5, AES, SSL, SHA-1, TLS 1.0, SSL 3.0, SSL 2.0, PEAP, TTLS, DSA, ECDSA, PKI, 128-bit AES, 192-bit AES, 256-bit AES, 256-bit SHA-2, 384-bit SHA-2, 256-bit SHA, 512-bit SHA-2, TLS 1.2, RNG, 512-bit SHA, 224-bit SHA-2, CRL, CCM, 384-bit SHA, CMAC, GCM, XTS, DRBG
Authentication Method
Secure Shell (SSH), RADIUS, X.509 certificates, TACACS+, Extensible Authentication Protocol (EAP)
Features
BOOTP support, ARP support, IGMP snooping, Syslog support, DoS attack prevention, port mirroring, DiffServ support, IPv6 support, SNTP support, sFlow, DHCP snooping, QoS, DHCP server, MLD snooping, DAI, PVST+, STP Root Guard, UDLD, fanless, LLDP support, DHCP relay, NTP server, DNS relay, DHCP client, Energy Efficient Ethernet, MIB, NAC, ToS, EPSRing, black hole routing, CPP, SLP, AMF, BIST, Cable fault locator (TDR), Link Aggregation, DDM, AAA, DNS client, NTP client, Voice VLAN, CFM, LLDP-MED, storm protection, proxy ARP, EEE, VLAN Tagging, LDF support, VACM, router advertisement guard, PoE Pass Through, BSR Mechanism, BPDU protection
Compliant Standards
IEEE 802.2, IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x, IEEE 802.1x, IEEE 802.3ac, IEEE 802.1ad, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, ITU-T G.8032, IEEE 802.3bt
RAM
512 MB DDR3 SDRAM
Flash Memory
128 MB
Status Indicators
Status
