General
Device Type
Switch - 16 ports - Managed
Enclosure Type
DIN rail mountable
Subtype
Gigabit Ethernet
Ports
16 x 10/100/1000
Performance
Switching capacity: 32 Gbps ¦ Forwarding performance (64-byte packet size): 23.8 Mpps
Capacity
VLAN groups: up to 256 ¦ Multicast groups: up to 256
MAC Address Table Size
8K entries
Jumbo Frame Support
10KB
Routing Protocol
IGMP
Remote Management Protocol
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, SSH-2, CLI
Features
VLAN support, IGMP snooping, Syslog support, port mirroring, store and forward, Broadcast Storm Control, half duplex mode, full duplex mode, Multicast Storm Control, firmware upgradable, SNTP support, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, VLAN Stacking, DHCP snooping, Quality of Service (QoS), DHCP server, Dynamic ARP Inspection (DAI), reset button, fanless, DHCP relay, Port Security, built-in DIP switch, Class of Service (CoS), tagged VLAN, 8KV ESD Protector, ONVIF support, 802.1x authentication, per port bandwidth control, ARP inspection, Management Information Base (MIB) II, DLF (Destination Lookup Failure), IGMP querier, VLAN Double Tagging (Q-in-Q), Root Guard, ground lift, BPDU Filter, MAC based VLAN, loopback detection, traffic monitoring, BPDU Guard, queue scheduling support, 8KV surge protection
Compliant Standards
IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1ab (LLDP), IEEE 802.3az, IEEE 802.1AX
RAM
128 MB
Built-in Devices
Led panel
