General
Device Type
Network surveillance camera
Audio Support
Yes: two-way audio capability
Audio Formats
PCM, G.726, ADPCM, AAC-LC, LPCM, G.711, OPUS
Form Factor
Dome
Camera Mount Type
Wall mount, ceiling mount
Connectivity Technology
Wired
Width
14.9 cm
Depth
14.9 cm
Height
10.3 cm
Weight
650 g
Camera
Type
Colour - Day&Night - fixed
Digital Video Format
MJPEG, H.264, HEVC, H.265, MPEG-4 AVC
Max Digital Video Resolution
1920 x 1080
Motion Detection
Yes
Video Modes
1080p
Exposure Range
2 sec - 1/66500 sec
Minimum Illumination
0.1 lux - colour - F1.8 - 50 IRE ¦ 0.02 lux - B&W - F1.8 - 50 IRE ¦ 0 lux - IR
Infrared LEDs
Yes
Infrared Distance
40 m
Video Capture
1920 x 1080 @ 60 fps
RAM
512 MB
Flash Memory
1024 MB
Features
Sharpness control, white balance, progressive scanning, saturation control, brightness control, contrast control, image mirror, Privacy Mask Function, full duplex audio, active tampering alarm, digital PTZ function, password protection, IR Corrected lens, Audio Detection, OptimizedIR, audible alerts, Zipstream technology, remote focus, ONVIF (Profile S) support, ONVIF (Profile G) support, exposure control, Pixel Counter Support, infrared-cut filter, Forensic WDR, IP address filtering, exposure zone, secure boot, Corridor mode, ONVIF (Profile T) support, Lightfinder 2.0 technology
Image Sensor
Type
CMOS 1/2.8"
Lens Construction
Type
Vari-focal
Optical Zoom
2.6 x
Focal Length
3.4 mm - 8.9 mm
Lens Iris
F/1.8 auto iris (P-Iris)
Horizontal Field of View (degree)
36 - 100
Vertical Field of View (degree)
20 - 53
Panning
Range (degree)
-180 to +180
Tilting
Range (degree)
-75 to +75
Interfaces
Network Interface
Ethernet 10Base-T/100Base-TX
Network Protocols
DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ARP, ICMP, SNMP 1, SNMP 2c, SNMP 3, SOCKS, RTSP, RTP, HTTPS, UPnP, TLS, IPv4, IPv6, Bonjour, RTCP, SMB, IGMP, SSH, SSL, QOS, CIFS, SRTP, EAP, SFTP, SIP, LLDP, USGv6
Expansion / Connectivity
Ports
LAN/power - RJ-45 ¦ Audio line-in/microphone - terminal block
Supported Memory Cards
microSD Card, microSDHC Card, microSDXC Card
Miscellaneous
Included Accessories
Cable gaskets, drill hole template, Resistorx T20 tool L-key, connector guard, terminal block connectors
Compliant Standards
EN55024, EN 61000-6-1, ICES-003 Class A, EN 61000-6-2, IEC 60068-2-30, IEC 60068-2-27, IEC 60068-2-6, IK10, IP52, FCC Part 15 B Class A, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-78, EN 50121-4, IEC 62236-4, VCCI Class A, NMB-3 Class A, RCM, IS13252, IEC EN60529, AS/NZS CISPR 32 Class A, EN 55032 Class A, KCC KN32 Class A, IEC/EN 62471, IEEE 802.3af, IEEE 802.3at, KCC KN35, IEC/EN 62262, IEC/EN/UL 62368-1, IEEE 802.1x, NIST SP500-267
Colour
White
Power
Power Requirements
DC 12 V / PoE Plus
Power Device
10.7 Watt
Software / System Requirements
Software Included
Windows decoder 1-user licence
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
50 °C
Relative Humidity (operating)
10 - 85% (non-condensing)
