General
Device Type
Network surveillance camera
Connectivity Technology
Wired
Width
11.6 cm
Depth
16 cm
Height
6.3 cm
Weight
780 g
Camera
Type
Colour - Day&Night - pan / tilt
Digital Video Format
H.264, MPEG-4, AVC, H.265, HEVC, MJPEG
Max Digital Video Resolution
1920 x 1080
Motion Detection
Yes
Video Modes
1080p
Exposure Range
2 sec - 1/33500 sec
Minimum Illumination
0.07 lux - colour - F1.9 - 30 IRE ¦ 0.14 lux - colour - F1.9 - 50 IRE ¦ 0.02 lux - B&W - F1.9 - 30 IRE ¦ 0.04 lux - B&W - F1.9 - 50 IRE ¦ 0 lux - IR
Infrared LEDs
Yes
Video Capture
1920 x 1080 @ 30 fps ¦ 1280 x 960 @ 45 fps
Still Image Capture Resolution
1080p
RAM
1 GB
Flash Memory
512 MB
Features
Lightfinder technology, Forensic WDR, Electronic Image Stabilizer (EIS), ONVIF (Profile S) support, ONVIF (Profile G) support, ONVIF (Profile T) support, progressive scanning, Zipstream technology, Variable Bitrate (VBR), Adaptive Bitrate (ABR), compression, brightness control, sharpness control, contrast control, white balance, exposure control, exposure zone, Corridor mode, image overlay, Privacy Mask Function, image mirror, defogging, digital PTZ function, guard tour, password protection, IP address filtering
Image Sensor
Type
RGB CMOS 1/2.9"
Lens Construction
Type
M12 mount - fixed focal
Focal Length
6 mm
Lens Iris
F/1.9 fixed iris
Horizontal Field of View (degree)
56
Vertical Field of View (degree)
30
Panning
Range (degree)
-20 to +20
Tilting
Range (degree)
0 to 15
Interfaces
Network Interface
Ethernet 10Base-T/100Base-TX
Network Protocols
EAP, TLS, IPv4, IPv6, USGv6, HTTP, HTTPS, SSL, QOS, FTP, SFTP, CIFS, SMB, SMTP, Bonjour, UPnP, SNMP 1, SNMP 2c, SNMP 3, DNS, DDNS, NTP, RTSP, RTP, SRTP, TCP/IP, UDP/IP, IGMP, IGMPv2, IGMPv3, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, LLDP, MQTT
Expansion / Connectivity
Ports
LAN/power - M12
Supported Memory Cards
microSD Card, microSDHC Card, microSDXC Card
Miscellaneous
Included Accessories
Drill hole template, lens tool, Resistorx L-key, masking kit
Compliant Standards
EN 50155, EN 45545-2, IEEE 802.1x, NEMA250 Type 4X, IEEE 802.3af, IEEE 802.3at, EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 B Class A, ICES-3(A)/NMB-3(A), VCCI Class A, AS/NZS CISPR 32 Class A, KCC KN32 Class A, KN35, EN 50121-4, EN 50121-3-2, IEC 62236-4, ECE-R10 Rev.6 (E approval), EN 50498, IEC/EN/UL 62368-1, CAN/CSA-C22.2 No. 62368-1, IEC/EN/UL 60950-22, CAN/CSA C22.2 No. 60950-22, UN ECE R118, IS13252, IEC 62471, IEC/EN 61373 Category 1 Class B, IEC/EN 60529 IP66, IEC/EN 60529 IP67, ISO 20653, IEC/EN 62262 IK10+, IEC 60721-3-5 Class 5M3, EN 50155:2017 Class OT2/ST2, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-64, NIST SP500-267, RCM, IP6K9K
Power
Power Requirements
PoE Class 3
Software / System Requirements
Software Included
Windows decoder 1-user licence
Manufacturer Warranty
Service & Support
Limited warranty - 5 years
Environmental Parameters
Min Operating Temperature
-40 °C
Max Operating Temperature
55 °C
Relative Humidity (operating)
10 - 95% (non-condensing)
