General
Device Type
Network surveillance camera
Audio Support
Yes: built-in microphone
Audio Formats
PCM, G.726, MP3, G.722.1, MP2L2, G.711a, G.711u
Form Factor
Turret
Connectivity Technology
Wired
Width
13.83 cm
Depth
13.83 cm
Height
12.01 cm
Weight
870 g
Localisation
Danish, Hungarian, Czech, Croatian, Slovenian, Thai, Slovak, Chinese (traditional), Vietnamese, Ukrainian, Brazilian Portuguese, English, German, French, Italian, Norwegian, Portuguese, Polish, Finnish, Swedish, Russian, Spanish, Dutch, Greek, Turkish, Bulgarian, Latvian, Lithuanian, Estonian, Serbian, Romanian, Japanese, Korean
Camera
Type
Colour - Day&Night - fixed - dustproof / waterproof
Digital Video Format
MJPEG, H.264, H.265, H.265+, H.264+
Max Digital Video Resolution
3840 x 2160
Motion Detection
Yes
Video Modes
4K
Exposure Range
1/3 sec - 1/100000 sec
Minimum Illumination
0.0005 lux - colour - F1.0 - AGC on
Infrared LEDs
Yes
Infrared Distance
30 m
Digital Video Capture Resolution
1280 x 720, 640 x 480, 1920 x 1080, 640 x 360, 3200 x 1800, 3840 x 2160, 2688 x 1520
Frame Rate (max)
60 frames per second
Features
Backlight Compensation (BLC), sharpness control, white balance, saturation control, brightness control, contrast control, e-mail alerts, image mirror, Wide Dynamic Range (WDR), Privacy Mask Function, Highlight Compensation (HLC), Scene Change Detection, password protection, Region of Interest (ROI), Variable Bitrate (VBR), Constant Bitrate (CBR), intrusion detection, ONVIF (Profile S) support, ONVIF (Profile G) support, Pixel Counter Support, Line Crossing Detection, heartbeat, anti-flicker, Internet Server Application Programming Interface (ISAPI), DORI coverage, Vehicle Detection, IP address filtering, 3D digital noise reduction (DNR), region exiting detection, region entrance detection, HTTPs encryption, human detection, White Light, ONVIF (Profile T) support, metal housing, Automatic Network Replenishment (ANR), Face Capture, smart supplement light, Gain Control, 24/7 colour imaging, rotate mode, 360° rotation, trigger capture, password reset via e-mail, WSSE, security audit log, video tampering alarm
Image Sensor
Type
8 MP PS CMOS 1/1.2"
Lens Construction
Type
M16 mount - fixed focal
Optical Zoom
1.4 x
Focal Length
2.8 mm - 4 mm
Lens Iris
F/1.0 fixed iris
Horizontal Field of View (degree)
88 - 102
Vertical Field of View (degree)
47 - 52
Diagonal Field of View (degree)
104 - 124
Panning
Range (degree)
0 to 360
Tilting
Range (degree)
0 to 75
Interfaces
Network Interface
Ethernet 10Base-T/100Base-TX
Network Protocols
DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ICMP, SNMP, RTSP, RTP, HTTPS, UPnP, TLS, IPv4, IPv6, Bonjour, PPPoE, IGMP, SSL, QOS, ISAPI, ISUP, SDK
Expansion / Connectivity
Ports
LAN/power - RJ-45
Supported Memory Cards
microSD Card, microSDHC Card, microSDXC Card
Miscellaneous
Compliant Standards
CB, IC, FCC CFR47 Part 15 B, REACH, IP67, LVD, KC, RCM, RoHS 2011/65/EU, TLS v1.2, TLS v1.1, WEEE 2012/19/EU, EN 55032:2015, UL 62368-1, Directive 1907/2006/EC, IEEE 802.1x, AS/NZS CISPR 32:2015, EN 50130-4:2011+A1:2014, KN32:2015, KN35:2015, IEC 60529:2013, EN 61000-3-2:2019, EN 62368-1:2014/A11:2017, EN 61000-3-3:2013+A1:2019, IEC 62368-1:2014+A11:2017, ICES-003 issue 7
Power
Power Requirements
DC 12 V / PoE - 0.46 A
Manufacturer Warranty
Service & Support
Limited warranty - 5 years
Dimensions & Weight (Shipping)
Shipping Width
17 cm
Shipping Depth
17 cm
Shipping Height
15 cm
Shipping Weight
1.16 kg
Environmental Parameters
Min Operating Temperature
-30 °C
Max Operating Temperature
60 °C
Relative Humidity (operating)
95% (non-condensing)
