General
Device Type
Network surveillance camera
Audio Support
Yes: two-way audio capability
Audio Formats
PCM, G.726, G.722.1, MP2L2, G.711a, G.711u
Form Factor
Dome
Connectivity Technology
Wired
Width
26.7 cm
Depth
26.7 cm
Height
43 cm
Weight
9.6 kg
Camera
Type
Colour - Day&Night - pan / tilt / zoom
Digital Video Format
MJPEG, H.264, H.265, H.265+, H.264+
Max Digital Video Resolution
3840 x 2160
Motion Detection
Yes
Digital Zoom
16
Exposure Range
1 sec - 1/30000 sec
Minimum Illumination
0.002 lux - colour - F1.5 - AGC on ¦ 0.0002 lux - B&W - F1.5 - AGC on ¦ 0 lux - IR
Infrared LEDs
Yes
Infrared Distance
500 m
Video Capture
3840 x 2160 @ 30 fps ¦ 2560 x 1440 @ 30 fps ¦ 1920 x 1080 @ 30 fps ¦ 1280 x 960 @ 30 fps ¦ 1280 x 720 @ 30 fps ¦ 704 x 576 @ 25 fps ¦ 704 x 480 @ 30 fps ¦ 640 x 480 @ 30 fps ¦ 352 x 288 @ 25 fps ¦ 352 x 240 @ 30 fps
Features
Backlight Compensation (BLC), sharpness control, saturation control, brightness control, contrast control, Wide Dynamic Range (WDR), ONVIF support, face detection, optical image stabilizer, window wiper, Privacy Mask Function, Highlight Compensation (HLC), NAS-Ready, Electronic Image Stabilizer (EIS), tamper-detection, triple video stream, Region of Interest (ROI), Defog, intrusion detection, auto white balance, 300 preset positions, 3D Digital Noise Reduction Technology, audio exception detection, object removal detection, Licence plate recognition (LPR), Line Crossing Detection, Internet Server Application Programming Interface (ISAPI), unattended baggage detection, Vehicle Detection, IP address filtering, region exiting detection, region entrance detection, HTTPs encryption, smart tracking, Rapid Focus, 8 patrols, 4 pattern scans, regional focus, regional exposure, up to 20 channels simultaneous live view, motion detection, Power-off Memory, face tracking, 3D Positioning, Preset Freezing, Automatic Network Replenishment (ANR), Face Capture, Auto Tracing White Balance, vandal-proof alarm, vehicle model recognition, vehicle colour recognition, DarkFighter technology
Lens Construction
Type
Motorized zoom
Optical Zoom
48 x
Focal Length
6 mm - 288 mm
Lens Iris
F/1.5
Focus Adjustment
Automatic, manual, semi-auto
Horizontal Field of View (degree)
2 - 60
Vertical Field of View (degree)
1.2 - 35.8
Diagonal Field of View (degree)
2.4 - 67
