General
Printer Fonts
PCL x 93 ¦ Bitmapped PCL x 10 ¦ PostScript x 136
Device Type
Multifunction printer
Printing Technology
Laser - monochrome
Display Diagonal Size
7"
Display Colour Support
Colour
Display Features
Touch screen, LCD display
Connection Availability
Yes
Interface
USB 2.0, Gigabit LAN, Wi-Fi(n), USB 2.0 host
AirPrint Enabled
Yes
Office Machine Features
Print from USB flash drive, scan to e-mail, scan to network, Data Security, scan to Cloud, scan to FTP, scan to SMB, Push Scan, fax to e-mail, Pull Scan, Color Network ScanGear2, fax to SMB, fax to FTP, Department ID, print from cloud, scan to USB host, scan to mobile device
Memory
Standard Memory
2 GB
Copying
Max Copying Speed
Up to 25 ppm
Max Copying Resolution
Up to 600 x 600 dpi
Max Document Enlargement
400%
Max Document Reduction
25%
Preset Enlargements
141%, 200%, 400%, 100%
Preset Reductions
25%, 50%, 70%
Maximum Copies
9999
Copying Features
ID Card Copy, Preset Reduction/Enlargement Ratios, Sort, Frame Erase Copy, Job Build, watermark, adjustable copy density, N-in-1, interrupt mode, book to two pages
Printing
Max Printing Resolution
Up to 600 x 600 dpi
Max Printing Speed
Up to 25 ppm
Printer Drivers / Emulations
PCL 6, PDF, TIFF, XPS, UFRII, JPEG, EPS
Automatic Duplexing
Yes
Scanning
Optical Resolution
600 x 600 dpi
Document & Media Handling
Max Original Size
297 x 432 mm
Original Type
Sheets, books
Min Media Size
95 x 139.7 mm
Max Media Size
A3
Min Media Weight
60 g/m²
Max Media Weight
157 g/m²
Supported Media Type
Transparencies, envelopes, plain paper, labels, recycled paper, bond paper, heavy-weight paper, thin paper, punched paper, coloured paper
Supported Media Sizes
A4 (210 x 297 mm), A5 (148 x 210 mm), B5 (176 x 250 mm), A3 (297 x 420 mm), B4 (250 x 353 mm), 297 x 431.8 mm, 95 x 139.7 mm
Supported Envelope Sizes
International DL (110 x 220 mm), Com-10 (105 x 241 mm), International C5 (162 x 229 mm), Monarch (98.4 x 190.5 mm)
Standard Media Capacity
330 sheets
Max Media Capacity
580 sheets
Output Trays Capacity
250 sheets
Document & Media Handling Details
Paper cassette - A3 (297 x 420 mm) weight: 64 g/m² - 90 g/m² ¦ Bypass tray size: 95 x 139.7 mm - 297 x 431.8 mm weight: 60 g/m² - 157 g/m² ¦ Output tray - 250 sheets ¦ Platen
Speed Details
Printing: up to 25 ppm (A4) ¦ Printing: up to 12 ppm (A3) ¦ Copying: up to 25 ppm (A4) ¦ Copying: up to 12 ppm (A3)
Connections
Interfaces
1 x USB 2.0 - 4 pin USB Type B ¦ 1 x Gigabit LAN - RJ-45 ¦ 3 x USB 2.0 host - 4 pin USB Type A
Security Protocols & Features
LDAP, Secure Print, TLS, IPsec, 802.1x, IP filtering, MAC address filtering, SNMP 3
Operating System Support
MS Windows 7, MS Windows Server 2008, MS Windows Server 2008 R2, MS Windows Server 2012, Android, iOS, Windows 8.1, MS Windows Server 2012 R2, Apple Mac OS X 10.10 or later, Windows 10, MS Windows Server 2016, MS Windows Server 2019
Software Included
Drivers & Utilities, iW Management Console, uniFLOW online Express, Canon Driver Configuration Tool
Power
Voltage Required
AC 230 V (50/60Hz)
Power Consumption Operational
1.5 kW
Power Consumption Standby
22.1 Watt
Power Consumption Sleep
1 Watt
Miscellaneous
Warm-Up Time
12 sec
First Copy Out Time B/W
7.4 sec
Environmental Standards
Blue Angel Compliant
Yes
Dimensions & Weight
Width
62.7 cm
Depth
66.5 cm
Height
51.6 cm
Weight
34.2 kg
Environmental Parameters
Sound Emission
54 dB (operating)
Min Operating Temperature
10 °C
Max Operating Temperature
30 °C
Humidity Range Operating
20 - 80%
