General
Type
Server
Recommended Use
Small business, corporate business
Product Form Factor
Rack-mountable - 2U
Embedded Security
Trusted Platform Module (TPM 1.2) Security Chip
Server Scalability
2-way
Hot-Swap Bays Qty
8
Localisation
Region: Worldwide (excluding China, Japan)
Processor / Chipset
CPU
Intel Xeon E5-2609V3
Clock Speed
1.9 GHz
Number of Cores
6-core
CPU Qty
1
Max CPU Qty
2
CPU Upgradability
Upgradable
Cache Memory
Installed Size
L3 Cache - 15 MB
Cache Per Processor
15 MB
RAM
Installed Size
8 GB (installed) / 384 GB (max)
Technology
DDR4 SDRAM
Effective Memory Speed
1600 MHz
Form Factor
DIMM 288-pin
Slots
24 (Total) / 23 (empty)
Features
Registered, HP SmartMemory
Configuration Features
1 x 8 GB
RAM Supported
PC4-17000 - 384 GB registered ¦ PC4-17000 - 768 GB Load-Reduced
Storage Controller
Type
1 x RAID - integrated
Controller Interface Type
SATA 6Gb/s
Storage Controller Name
HP Dynamic Smart Array B140i
Channel Qty
10
RAID Level
RAID 0, RAID 1, RAID 5, RAID 10
Optical Storage
Type
No optical drive
Monitor
Monitor Type
None.
Graphics Controller
Type
Integrated
Graphics Processor
Matrox G200eH2
Video Interfaces
VGA
Networking
Type
Integrated
Interface (Bus) Type
PCI Express x2
Ethernet Ports
4 x Gigabit Ethernet
Ethernet Controller
HP 331i
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller
Integrated Lights-Out 4
Features
Wake on LAN (WoL), PXE support
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Expansion / Connectivity
Bays
8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots
2 (total) / 1 (free) x CPU ¦ 24 (total) / 23 (free) x DIMM 288-pin ¦ 2 (total) / 2 (free) x PCIe 3.0 x16 - half-length, full-height (x8 mode) ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 - half-length, full-height ¦ 1 (total) / 1 (free) x microSD Card (internal)
Interfaces
4 x LAN (Gigabit Ethernet) - RJ-45 ¦ 1 x HPE iLO - RJ-45 ¦ 1 x VGA ¦ 5 x USB 3.0 (1 front, 2 rear, 2 internal)
Miscellaneous
Included Accessories
HP Easy Install Rails
Features
Administrator password, power-on password, serial port I/O control, UEFI BIOS
Compliant Standards
ACPI 2.0b, FCC Class A certified, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, FCC CFR47 Part 15, IEC 60950-1, EN 60950-1, WEEE, GB 9254, CNS 13438
Power
Device Type
Power supply - hot-plug
Power Redundancy
Optional
Power Redundancy Scheme
1+1 (with optional power supply)
Installed Qty
1
Max Supported Qty
2
Voltage Required
AC 120/230 V
Power Provided
500 Watt
80 PLUS Certification
80 PLUS Platinum
Efficiency
94%
Operating System / Software
OS Certified
SUSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, Oracle Solaris, Citrix XenServer, Canonical Ubuntu
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Dimensions & Weight
Width
44.55 cm
Depth
67.94 cm
Height
8.73 cm
Weight
14.759 kg
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% (non-condensing)
Sound Emission
24 dBA
