General
Type
Server
Product Form Factor
Rack-mountable - 2U
Built-in Devices
Led panel
Server Scalability
2-way
Hot-Swap Bays Qty
8
Processor / Chipset
CPU
AMD EPYC 7301
Clock Speed
2.2 GHz
Max Turbo Speed
2.7 GHz
Number of Cores
16-core
CPU Qty
1
Max CPU Qty
2
CPU Upgradability
Upgradable
Cache Memory
Installed Size
L3 Cache - 64 MB
Cache Per Processor
64 MB
RAM
Installed Size
32 GB / 1 TB (max)
Technology
DDR4 SDRAM
Effective Memory Speed
2666 MHz
Form Factor
DIMM 288-pin
Slots
32 (Total)
Features
Registered, mixing of different types of memory modules is not supported, 8-channel memory architecture, HPE SmartMemory, slots 17 - 32 are available in two-processor configuration only
RAM Supported
PC4-20800 - 1 TB registered ¦ PC4-20800 - 4 TB Load-Reduced
Hard Drive
Type
HDD
Capacity
2 x 300 GB
Interface Type
SAS
Storage Controller
Type
1 x RAID - PCIe 3.0 x8
Controller Interface Type
SATA 6Gb/s / SAS 12Gb/s
Storage Controller Name
HPE Smart Array P408i-a
Channel Qty
8
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, 1ADM, 10ADM
Buffer Size
2 GB
Optical Storage
Type
DVD-Writer
Monitor
Monitor Type
None.
Graphics Controller
Video Memory
16 MB
Video Interfaces
VGA, DisplayPort
Networking
Ethernet Ports
4 x Gigabit Ethernet
Ethernet Controller
HPE 331i
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
SNMP 3, IPMI 2.0, SMASH CLP
Remote Management Controller
Integrated Lights-Out 5
Features
Wake on LAN (WoL), ACPI support, PXE support
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1as, IEEE 802.3az
Expansion / Connectivity
Bays
8 (total) / 6 (free) x hot-swap 2.5" SFF ¦ 1 (total) / 0 (free) x external Universal Media Bay
Slots
1 (total) / 0 (free) x FlexibleLOM ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - half-length, full-height ¦ 2 (total) / 2 (free) x PCIe 3.0 x8 - half-length, full-height ¦ 1 (total) / 1 (free) x microSD Card (internal)
Interfaces
1 x HPE iLO - Type A (1 in front) ¦ 5 x USB 3.0 (1 front, 2 rear, 2 internal) ¦ 4 x LAN (Gigabit Ethernet) - RJ-45 (4 rear) ¦ 1 x HPE iLO - RJ-45 (1 rear) ¦ 1 x VGA (1 rear) ¦ 2 x USB 2.0 (2 in front) ¦ 1 x DisplayPort (1 in front)
Miscellaneous
Included Accessories
HPE Easy Install Rails, 6 x standard hot plug fans, CPU standard heatsink
Compliant Standards
AES, FIPS 140-2, IPv6 Ready, PCI DSS, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.1
Manufacturer Selling Program
HPE Top Value
Power
Device Type
Power supply - hot-plug
Power Redundancy
Optional
Power Redundancy Scheme
1+1 (with optional power supply)
Installed Qty
2
Max Supported Qty
2
Voltage Required
AC 120/230 V (50/60 Hz)
Power Provided
800 Watt
Operating System / Software
Software
HPE Server UEFI, HPE OneView Standard (free download)
Sustainability Information
ENERGY STAR Certified
Yes
ENERGY STAR Version
2.1
Dimensions & Weight
Width
44.55 cm
Depth
67.94 cm
Height
8.73 cm
Weight
14.9 kg
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% (non-condensing)
