General
Type
Server
Product Form Factor
Rack-mountable - 2U
Built-in Devices
Led panel, battery
Server Scalability
2-way
Hot-Swap Bays Qty
8
Processor / Chipset
CPU
AMD EPYC 7351
Clock Speed
2.4 GHz
Number of Cores
16-core
CPU Qty
1
Max CPU Qty
2
CPU Upgradability
Upgradable
Cache Memory
Installed Size
L3 Cache - 64 MB
Cache Per Processor
64 MB
RAM
Installed Size
32 GB (installed) / 4 TB (max)
Technology
DDR4 SDRAM - ECC
Effective Memory Speed
2600 MHz
Rated Memory Speed
2600 MHz
Memory Specification Compliance
PC4-20800
Form Factor
DIMM 288-pin
Slots
32 (Total) / 30 (empty)
Features
Registered, slots 13 - 24 are available in two-processor configuration only, HPE SmartMemory
Configuration Features
2 x 16 GB
RAM Supported
PC4-20800 - 1 TB registered ¦ PC4-20800 - 4 TB Load-Reduced
Storage Controller
Type
1 x RAID - PCIe 3.0 x8
Controller Interface Type
SATA 6Gb/s / SAS 12Gb/s
Storage Controller Name
HPE Smart Array P408i-a
Channel Qty
8
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, RAID 1 ADM, RAID 10 ADM
Buffer Size
2 GB
Storage Controller (2nd)
Type
SATA
Storage Controller Name
HPE Smart Array S100i SR Software
Optical Storage
Type
No optical drive
Card Reader
Type
Card reader
Supported Flash Memory Cards
microSD
Monitor
Monitor Type
None.
Graphics Controller
Video Memory
16 MB
Video Interfaces
VGA
Networking
Interface (Bus) Type
PCI Express 2.0 x4
Ethernet Ports
4 x Gigabit Ethernet
Ethernet Controller
HPE 331i
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
SNMP 3, IPMI 2.0, SMASH CLP
Remote Management Controller
Integrated Lights-Out 5
Features
Wake on LAN (WoL), ACPI support, PXE support
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1as, IEEE 802.3az
Expansion / Connectivity
Bays
1 (total) / 1 (free) x external Universal Media Bay ¦ 8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots
1 (total) / 0 (free) x FlexibleLOM ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - half-length, full-height ¦ 2 (total) / 2 (free) x PCIe 3.0 x8 - half-length, full-height ¦ 1 (total) / 1 (free) x microSD Card (internal)
Interfaces
1 x HPE iLO (1 in front) ¦ 1 x HPE iLO (1 rear) ¦ 4 x LAN (Gigabit Ethernet) (4 rear) ¦ 5 x USB 3.0 (1 front, 2 rear, 2 internal) ¦ 1 x VGA (1 rear)
Miscellaneous
Included Accessories
HPE Easy Install Rails
Compliant Standards
AES, FIPS 140-2, IPv6 Ready, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.1
Power
Device Type
Power supply - hot-plug
Power Redundancy
Optional
Power Redundancy Scheme
1+1 (with optional power supply)
Installed Qty
1
Max Supported Qty
2
Voltage Required
AC 120/230 V (50/60 Hz)
Power Provided
800 Watt
Operating System / Software
Software
HPE Server UEFI, HPE iLO Advanced, HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download)
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Dimensions & Weight
Width
44.54 cm
Depth
73.02 cm
Height
9.73 cm
Weight
14.9 kg
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% (non-condensing)
Sound Emission
37 dBA
