General
Type
Personal computer
Product Form Factor
SFF
Embedded Security
Firmware Trusted Platform Module (TPM 2.0) Security Chip
Processor / Chipset
CPU
Intel Core i5 (10th Gen) 10505
Clock Speed
3.2 GHz
Max Turbo Speed
4.6 GHz
Number of Cores
6-core
CPU Qty
1
Max CPU Qty
1
CPU Upgradability
Upgradable
Processor Main Features
Intel Turbo Boost Technology 2, Intel Smart Cache
CPU Socket
FCLGA1200 Socket
Chipset Type
Intel B460
Cache Memory
Installed Size
L3 Cache - 12 MB
Cache Per Processor
12 MB
RAM
Installed Size
8 GB (installed) / 64 GB (max)
Technology
DDR4 SDRAM - non-ECC
Effective Memory Speed
2666 MHz
Rated Memory Speed
2666 MHz
Memory Specification Compliance
PC4-21333
Form Factor
DIMM 288-pin
Slots
2 (Total) / 1 (empty)
Features
Unbuffered, dual channel memory architecture
Configuration Features
1 x 8 GB
Hard Drive
Type
SSD - M.2 2280
Capacity
1 x 512 GB
Interface Type
PCI Express
Features
NVM Express (NVMe)
Storage Controller
Type
1 x SATA
Controller Interface Type
SATA 6Gb/s
Optical Storage
Type
DVD-Writer
Card Reader
Type
Card reader
Supported Flash Memory Cards
SD Memory Card, SDHC Memory Card, SDXC Memory Card
Monitor
Monitor Type
None.
Graphics Controller
Graphics Processor
Intel UHD Graphics 630
Video Interfaces
VGA, HDMI
HDCP Compatible
Yes
Audio Output
Max Sampling Rate
192 kHz
Compliant Standards
High Definition Audio
Input Device
Type
Mouse, keyboard
Mouse
Technology
Optical
Interface
USB
Networking
Wireless LAN Supported
Yes
Wireless NIC
Realtek RTL8821CE
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 4.2
Remote Management Protocol
SNMP 2
Features
Wake on LAN (WoL), ACPI support, PXE 2.1 support
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3ab
Expansion / Connectivity
Bays
1 (total) / 0 (free) x internal 2 x 2.5"/3.5" shared ¦ 1 (total) / 1 (free) x external 3.5"
Slots
1 (total) / 1 (free) x PCIe x16 ¦ 1 (total) / 1 (free) x PCIe x1 ¦ 1 (total) / 0 (free) x M.2 Card ¦ 1 (total) / 0 (free) x M.2 Card - 2242/2280
Interfaces
4 x USB 3.2 Gen 1 (4 in front) ¦ 1 x headphones/microphone (1 in front) ¦ 1 x audio line-in ¦ 1 x audio line-out ¦ 1 x HDMI ¦ 1 x VGA ¦ 4 x USB 2.0 ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x serial
Miscellaneous
Included Accessories
HP Drivers RTF Card
Theft/Intrusion Protection
Security lock slot (cable lock sold separately), padlock loop
Security Slot Type
Kensington security slot
Power
Device Type
Power supply
Voltage Required
AC 120/230 V (50/60 Hz)
Power Provided
180 Watt
80 PLUS Certification
80 PLUS Gold
Power Factor Correction
Yes (active)
Operating System / Software
OS Provided
Windows 10 Pro 64-bit Edition
Software
HP Support Assistant, Amazon, Netflix, HP Setup Integrated OOBE, HP System Event Utility, Dropbox (25 GB Cloud Storage) (free for 1 year), HP Documentation, HP Audio Switch, HP JumpStart, Xerox DocuShare (30 days trial)
Sustainability Information
ENERGY STAR Certified
Yes
Dimensions & Weight
Width
27 cm
Depth
29.6 cm
Height
9.5 cm
Weight
4 kg
Dimensions & Weight (Shipping)
Shipping Width
34.2 cm
Shipping Depth
19.6 cm
Shipping Height
49.9 cm
Shipping Weight
6 kg
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% (non-condensing)
