General
Type
Personal computer
Product Form Factor
SFF
Sensors
HP Tamper Lock
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Language: English / region: United Kingdom
Processor / Chipset
CPU
Intel Core i7 (14th Gen) i7-14700
Clock Speed
2.1 GHz (P-core) / 1.5 GHz (E-core)
Max Turbo Speed
5.4 GHz (P-core) / 4.2 GHz (E-core)
Number of Cores
20-core
CPU Qty
1
Max CPU Qty
1
L2 cache
28 MB
CPU Upgradability
Upgradable
Processor Main Features
Intel Turbo Boost Technology
Chipset Type
Intel Q670
Cache Memory
Installed Size
L3 Cache - 33 MB
Cache Per Processor
33 MB
RAM
Installed Size
16 GB (installed) / 128 GB (max)
Technology
DDR5 SDRAM
Effective Memory Speed
4800 MHz
Rated Memory Speed
4800 MHz
Form Factor
DIMM 288-pin
Slots
4 (Total) / 3 (empty)
Features
Unbuffered
Configuration Features
1 x 16 GB
Hard Drive
Type
SSD - M.2 2280
Capacity
1 x 512 GB
Interface Type
PCI Express
Features
NVM Express (NVMe)
Storage Controller
Type
1 x SATA/NVMe
Controller Interface Type
SATA-600 / NVMe
Channel Qty
4
Optical Storage
Type
DVD-Writer
Monitor
Monitor Type
None.
Graphics Controller
Graphics Processor
Intel UHD Graphics 770 Dynamic Video Memory Technology
Video Interfaces
HDMI, DisplayPort
HDCP Compatible
Yes
Audio Output
Sound Output Mode
Stereo
Max Sampling Rate
192 kHz
Compliant Standards
High Definition Audio
Input Device
Type
Mouse, keyboard
Keyboard
Keyboard Name
HP 125
Interface
USB
Localization & Layout
UK
Networking
Interface (Bus) Type
PCI Express Mini Card (M.2)
Ethernet Controller
Intel I219-LM
Wireless LAN Supported
Yes
Wireless NIC
Intel WI-FI 7 BE200
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11be, IEEE 802.11ax (Wi-Fi 6), Bluetooth 5.4
Remote Management Protocol
SNMP 2
Features
Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), PXE 2.1 support, dual stream (2x2)
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.1x, IEEE 802.11i, Wi-Fi CERTIFIED, IEEE 802.11h, IEEE 802.11k, IEEE 802.3az, IEEE 802.11r, IEEE 802.11v
Expansion / Connectivity
Bays
2 (total) / 2 (free) x internal 3.5" ¦ 1 (total) / 0 (free) x external 5.25" Slim Line
Slots
1 (total) / 0 (free) x M.2 Card - 2230 (for wireless module) ¦ 2 (total) / 1 (free) x M.2 Card - 2280 (for internal storage) ¦ 2 (total) / 2 (free) x PCIe 3.0 x1 ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 (x4 mode) ¦ 1 (total) / 1 (free) x PCIe 4.0 x16
Interfaces
1 x USB-C 3.2 Gen 2x2 (1 in front) (charging) ¦ 4 x USB 3.2 Gen 2 (4 in front) (one of them is charging) ¦ 1 x headphones/microphone (1 front) (CTIA and OMTP headset support) ¦ 1 x audio line-out/line-in ¦ 2 x DisplayPort 1.4a ¦ 3 x USB 2.0 (3 rear) (two of them with wake functionality) ¦ 3 x USB 3.2 Gen 1 (3 rear) ¦ 1 x LAN (Gigabit Ethernet) - RJ-45 ¦ 1 x HDMI
Miscellaneous
Theft/Intrusion Protection
Security lock slot (cable lock sold separately), padlock loop, chassis intrusion sensor
Security Slot Type
Kensington security slot
Compliant Standards
FCC Class B certified, ICES-003, CCC, FIPS 140-2 Level 2, RoHS, UL 60950-1, CSA C22.2 No. 60950-1-07, WEEE, KCC Class B, Common Criteria EAL4+, CECP, VCCI Class B, SEPA, low halogen, UL 62368-1, CAN/CSA-C22.2 No. 62368-1-14, IEEE 1680.1
Power
Device Type
Power supply
Voltage Required
AC 90-264 V (50/60 Hz)
Power Provided
260 Watt
80 PLUS Certification
80 PLUS Platinum
Efficiency
92%
Power Factor Correction
Yes (active)
Operating System / Software
OS Provided
Windows 11 Pro English
Software
HP Support Assistant, HP PC Hardware Diagnostics UEFI, HP Secure Erase, HP Drive Packs (free download), HP Client Catalogue (free download), HP Setup Integrated OOBE, HP Notifications, HP Connection Optimizer, HP Sure Click, HP Privacy Settings, HP Cloud Recovery, HP Sure Sense, HP Sure Admin, HP QuickDrop, HP Client Management Script Library (free download), HP BIOSphere Gen6, HP Desktop Support Utilities, HP Image Assistant Gen5 (free download), HP SureStart Gen7, HP Smart Support, HP Manageability Integration Kit (free download), HP Connect for Microsoft Endpoint Manager, HP Patch Assistant (free download), HP Sure Recover Gen5, HP Sure Run Gen5, HP Services Scan
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 1 year - on-site
Dimensions & Weight
Width
33.8 cm
Depth
30.8 cm
Height
10 cm
Weight
5.04 kg
Dimensions & Weight (Shipping)
Shipping Width
39.9 cm
Shipping Depth
49.9 cm
Shipping Height
23 cm
Shipping Weight
7.92 kg
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
10 - 90% RH (non-condensing)
