General
Platform Technology
Intel vPro Platform
Type
Personal computer
Bundled Services
HP 3 years Next Business Day Onsite Hardware Support for Desktops
Product Form Factor
SFF
Sensors
HP Tamper Lock
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Language: English / region: United Kingdom
Processor / Chipset
CPU
Intel Core i9 (12th Gen) 12900
Clock Speed
2.4 GHz (P-core) / 1.8 GHz (E-core)
Max Turbo Speed
5.1 GHz (P-core) / 3.8 GHz (E-core)
Number of Cores
16-core
CPU Qty
1
Max CPU Qty
1
L2 cache
14 MB
CPU Upgradability
Upgradable
Processor Main Features
Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache, Intel Turbo Boost Max 3.0, Intel vPro Platform Eligibility
Chipset Type
Intel Q670
Cache Memory
Installed Size
L3 Cache - 30 MB
Cache Per Processor
30 MB
RAM
Installed Size
32 GB (installed) / 128 GB (max)
Technology
DDR5 SDRAM
Effective Memory Speed
4800 MHz
Rated Memory Speed
4800 MHz
Form Factor
DIMM 288-pin
Slots
4 (Total) / 2 (empty)
Features
Unbuffered
Configuration Features
2 x 16 GB
Hard Drive
Type
SSD - M.2 2280
Capacity
1 x 512 GB
Interface Type
PCI Express
Features
NVM Express (NVMe)
Storage Controller
Type
1 x SATA/NVMe
Controller Interface Type
SATA-600 / NVMe
Channel Qty
4
Optical Storage
Type
No optical drive
Monitor
Monitor Type
None.
Graphics Controller
Graphics Processor
Intel UHD Graphics 770 Dynamic Video Memory Technology
Video Interfaces
HDMI, DisplayPort
HDCP Compatible
Yes
Audio Output
Sound Output Mode
Stereo
Max Sampling Rate
192 kHz
Compliant Standards
High Definition Audio
Input Device
Type
Mouse, keyboard
Keyboard
Keyboard Name
HP 655
Connectivity
Wireless
Localization & Layout
UK
Mouse
Mouse Name
HP 128
Technology
Laser
Networking
Ethernet Controller
Intel I219-LM
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
SNMP 2
Features
Wake on LAN (WoL), ACPI support, PXE 2.1 support
Expansion / Connectivity
Bays
1 (total) / 1 (free) x external 5.25" Slim Line ¦ 2 (total) / 2 (free) x external 3.5"
Slots
1 (total) / 1 (free) x PCIe 4.0 x16 ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 (x4 mode) ¦ 2 (total) / 2 (free) x PCIe 3.0 x1 ¦ 1 (total) / 0 (free) x M.2 Card - 2230 (for wireless module) ¦ 2 (total) / 1 (free) x M.2 Card - 2280 (for internal storage)
Interfaces
3 x USB 2.0 ¦ 3 x USB 3.2 Gen 1 (one of them is fast-charging) ¦ 4 x USB 3.2 Gen 2 (4 in front) ¦ 1 x USB-C 3.2 Gen 2x2 ¦ 2 x DisplayPort 1.4a ¦ 1 x headphones/microphone (1 in front) (CTIA headset support) ¦ 1 x audio line-out/line-in (1 rear) ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x HDMI ¦ 1 x USB 3.1 Gen 2
Miscellaneous
Theft/Intrusion Protection
Security lock slot (cable lock sold separately), padlock loop
Security Slot Type
Kensington security slot
Compliant Standards
FCC Class B certified, ICES-003, CCC, FIPS 140-2 Level 2, RoHS, UL 60950-1, CSA C22.2 No. 60950-1-07, WEEE, KCC Class B, Common Criteria EAL4+, CECP, VCCI Class B, SEPA, low halogen, UL 62368-1, CAN/CSA-C22.2 No. 62368-1-14, IEEE 1680.1
Power
Device Type
Power supply
Voltage Required
AC 90-264 V (50/60 Hz)
80 PLUS Certification
80 PLUS Platinum
Power Factor Correction
Yes (active)
Operating System / Software
OS Provided
Windows 11 Pro English
Software
HP Support Assistant, Windows Defender, Microsoft 365 (Trial), HP Secure Erase, HP Setup Integrated OOBE, HP PC Hardware Diagnostics, HP Notifications, HP Connection Optimizer, HP Sure Click, HP Privacy Settings, HP Cloud Recovery, HP Sure Sense, HP Sure Admin, HP QuickDrop, HP WorkWell, HP SureStart Gen6, HP BIOSphere Gen6, HP Wake on WLAN, myHP, Touchpoint Customiser for Commercial, HP Desktop Support Utilities, HP Tamper Lock, HP Noise Cancellation Software, HP Client Security Manager Gen7, HP SureRun Gen4, HP Sure Recover Gen4, HP SureStart Gen7, HP Easy Clean, HP Sure Recover Gen5, HP Sure Sense Gen2, HP Sure Run Gen5
Sustainability Information
TCO Certified
TCO Certified Desktops 9
ENERGY STAR Certified
Yes
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 1 year - on-site
Dimensions & Weight
Width
33.8 cm
Depth
30.8 cm
Height
10 cm
Weight
5.04 kg
Dimensions & Weight (Shipping)
Shipping Width
39.9 cm
Shipping Depth
49.9 cm
Shipping Height
23 cm
Shipping Weight
7.92 kg
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
10 - 90% (non-condensing)
