General
Platform Technology
Intel vPro Platform
Type
Personal computer
Product Form Factor
All-in-one - with height-adjustable stand
Built-in Devices
Dual 5 W speakers
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Language: English / region: United Kingdom
Bundled with
HP Wolf Pro Security Edition (3 years)
Processor / Chipset
CPU
Intel Core i5 (10th Gen) 10500
Clock Speed
3.1 GHz
Max Turbo Speed
4.5 GHz
Number of Cores
6-core
CPU Qty
1
Max CPU Qty
1
CPU Upgradability
Upgradable
Processor Main Features
Intel Turbo Boost Technology
Chipset Type
Intel Q470
Cache Memory
Installed Size
L3 Cache - 12 MB
Cache Per Processor
12 MB
RAM
Installed Size
8 GB / 64 GB (max)
Technology
DDR4 SDRAM - non-ECC
Effective Memory Speed
2666 MHz
Rated Memory Speed
2666 MHz
Form Factor
SO-DIMM 260-pin
Slots
2 (Total) / 1 (empty)
Configuration Features
1 x 8 GB
Hard Drive
Type
SSD - M.2 2280
Capacity
1 x 256 GB
Interface Type
PCI Express 3.0 x4 (NVMe)
Features
NVM Express (NVMe), triple-level cell (TLC)
Storage Controller
Type
1 x SATA/NVMe
Controller Interface Type
SATA-600 / NVMe
Optical Storage
Type
No optical drive
Monitor
Monitor Type
LED - IPS
Touchscreen
Yes
Diagonal Size
23.8"
Native Resolution
1920 x 1080 (Full HD)
Widescreen Display
Yes
Image Aspect Ratio
16:9
Horizontal Viewing Angle
178
Vertical Viewing Angle
178
Colour Gamut
72% NTSC
Pixel Pitch
0.2745 mm
Response Time
14 ms
Image Brightness
250 cd/m²
Image Contrast Ratio
1000:1
Monitor Features
Anti-glare, Frame Rate Control (FRC), tilt stand (-5°- 18°), 90° screen rotation, adjustable height (130 mm)
Graphics Controller
Graphics Processor
Intel UHD Graphics 630
Video Interfaces
HDMI, DisplayPort
HDCP Compatible
Yes
Audio Output
Sound Output Mode
Stereo
Max Sampling Rate
192 kHz
Compliant Standards
High Definition Audio
Speakers
Bang & Olufsen sound bar
Speakers Included
2 x right / left channel
Camera
Camera
Yes
Resolution (MP)
5 Megapixel
Resolution
Full HD
Input Device
Type
Mouse, keyboard
Keyboard
Keyboard Name
HP Business Slim Keyboard
Connectivity
Wireless
Localization & Layout
UK
Mouse
Connectivity
Wireless
Audio Input
Type
Dual array microphone
Networking
Ethernet Controller
Intel I219-LM
Wireless LAN Supported
Yes
Wireless NIC
Intel Wi-Fi 6 AX 201
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), Bluetooth 5.1
Remote Management Protocol
SNMP 2
Features
Wake on LAN (WoL), auto-uplink (auto MDI/MDI-X), MU-MIMO Support, PXE 2.1 support, dual stream (2x2), Miracast compatible
Compliant Standards
IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.1x, IEEE 802.11i, Wi-Fi CERTIFIED, IEEE 802.3az
Expansion / Connectivity
Slots
1 (total) / 0 (free) x M.2 Card - 2230 (x1 mode) ¦ 2 (total) / 1 (free) x M.2 Card - 2280 (x4 mode)
Interfaces
3 x USB 3.2 Gen 2 (charging) ¦ 2 x USB-C 3.2 Gen 2 (charging) ¦ 1 x headphones/microphone (CTIA and OMTP headset support) ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x DisplayPort ¦ 2 x USB 3.2 Gen 1 ¦ 1 x HDMI
Miscellaneous
Theft/Intrusion Protection
Security lock slot (cable lock sold separately)
Security Slot Type
Kensington security slot
VESA Mounting Interface
100 x 100 mm
Compliant Standards
FCC Class B certified, ICES-003, CCC, RoHS, UL 60950-1, CSA C22.2 No. 60950-1-07, WEEE, KCC Class B, Common Criteria EAL4+, CECP, VCCI Class B, SEPA, low halogen, UL 62368-1, CAN/CSA-C22.2 No. 62368-1-14, IEEE 1680.1
Power
Device Type
Power supply
Voltage Required
AC 120/230 V (50/60 Hz)
Operating System / Software
OS Provided
Windows 10 Pro 64-bit Edition English
Software
HP Support Assistant, Windows Defender, Microsoft 365 (30 days trial), HP Secure Erase, HP Setup Integrated OOBE, HP JumpStart, HP Noise Cancellation, HP Sure Click, HP Privacy Settings, HP Cloud Recovery, HP Sure Sense, Intel Unite Plus Lync Plug-in, HP Sure Recover Gen3, HP SureStart Gen6, HP Sure Run Gen3, HP BIOSphere Gen6, HP DriveLock, HP Wake on WLAN, HP Desktop Support Utility, HP Client Security Suite Gen6
Environmental Standards
ENERGY STAR Certified
Yes
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site
Dimensions & Weight
Dimensions & Weight Details
53.972 cm - 23.698 cm - 54.114 cm - 10.36 kg - with stand
Width
53.972 cm
Depth
5.93 cm
Height
36.43 cm
Weight
7.94 kg
Dimensions & Weight (Shipping)
Shipping Width
62.8 cm
Shipping Depth
18.6 cm
Shipping Height
63.5 cm
Shipping Weight
12.35 kg
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
10 - 90% (non-condensing)
