General
Type
Personal computer
Product Form Factor
Small form factor
Built-in Devices
Speaker
Sensors
HP Tamper Lock
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Language: English / region: United Kingdom
Processor / Chipset
CPU
Intel Core i5 (12th Gen) 12500
Clock Speed
3 GHz
Max Turbo Speed
4.6 GHz
Number of Cores
6-core
CPU Qty
1
Max CPU Qty
1
CPU Upgradability
Upgradable
Processor Main Features
Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Turbo Boost Max 3.0
Chipset Type
Intel Q670
Cache Memory
Installed Size
L3 Cache - 18 MB
Cache Per Processor
18 MB
RAM
Installed Size
16 GB / 64 GB (max)
Technology
DDR4 SDRAM - non-ECC
Effective Memory Speed
3200 MHz
Rated Memory Speed
3200 MHz
Form Factor
DIMM 288-pin
Slots
2 (Total) / 1 (empty)
Features
Unbuffered
Configuration Features
1 x 16 GB
Hard Drive
Type
SSD - M.2 2280
Capacity
1 x 256 GB
Interface Type
PCI Express
Features
NVM Express (NVMe)
Storage Controller
Type
1 x SATA
Channel Qty
3
Optical Storage
Type
No optical drive
Monitor
Monitor Type
None.
Graphics Controller
Graphics Processor
Intel UHD Graphics 770 Dynamic Video Memory Technology
Video Interfaces
HDMI, DisplayPort
HDCP Compatible
Yes
Audio Output
Sound Output Mode
Stereo
Max Sampling Rate
192 kHz
Compliant Standards
High Definition Audio
Input Device
Type
Mouse, keyboard
Keyboard
Keyboard Name
HP 320K
Interface
USB
Localization & Layout
UK
Mouse
Mouse Name
HP 125
Interface
USB
Networking
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
SNMP 2
Features
Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), PXE 2.1 support
Expansion / Connectivity
Bays
1 (total) / 1 (free) x external 5.25" Slim Line ¦ 1 (total) / 1 (free) x internal 3.5"
Slots
1 (total) / 1 (free) x PCIe 4.0 x16 ¦ 1 (total) / 1 (free) x PCIe 3.0 x1 ¦ 1 (total) / 1 (free) x M.2 Card - 2230 (PCIe x1 mode (for wireless module)) ¦ 1 (total) / 0 (free) x M.2 Card - 2280 (PCIe x4 mode (for internal storage))
Interfaces
1 x headphones/microphone (1 in front) (CTIA and OMTP headset support) ¦ 3 x USB 3.2 Gen 2 (3 in front) ¦ 1 x USB-C 3.2 Gen 2 (1 in front) ¦ 1 x audio line-out/line-in ¦ 1 x DisplayPort 1.4a ¦ 1 x HDMI ¦ 2 x USB 2.0 (wake functionality) ¦ 3 x USB 3.2 Gen 1 ¦ 1 x LAN (Gigabit Ethernet)
Miscellaneous
Theft/Intrusion Protection
Security lock slot (cable lock sold separately), padlock loop, chassis intrusion sensor
Security Slot Type
Kensington security slot
Compliant Standards
FCC Class B certified, ICES-003, CCC, FIPS 140-2 Level 2, RoHS, WEEE, KCC Class B, Common Criteria EAL4+, VCCI Class B, low halogen, CAN/CSA-C22.2 No. 62368-1, UL 62368-1, IEEE 1680.1-2018
Power
Device Type
Power supply
Voltage Required
AC 90-264 V (50/60 Hz)
Power Provided
240 Watt
80 PLUS Certification
80 PLUS Platinum
Efficiency
90% at 20% Load (115 VAC), 92% at 50% Load (115 VAC), 89% at 100% Load (115 VAC), 91% at 20% Load (230 VAC), 93% at 50% Load (230 VAC), 90% at 100% Load (230 VAC)
Power Factor Correction
Yes (active)
Operating System / Software
OS Provided
Windows 10 Pro (available through downgrade rights from Windows 11 Pro) + Windows 11 Pro Licence - English
Software
HP Support Assistant, HP PC Hardware Diagnostics UEFI, HP Secure Erase, HP Client Catalogue (free download), HP Setup Integrated OOBE, HP Notifications, HP Connection Optimizer, HP Privacy Settings, HP Cloud Recovery, HP QuickDrop, HP Client Management Script Library (free download), HP BIOSphere Gen6, myHP, Touchpoint Customiser for Commercial, HP Desktop Support Utilities, HP Image Assistant Gen5 (free download), HP Easy Clean, HP Smart Support, HP Manageability Integration Kit (free download), HP Patch Assistant (free download)
Environmental Standards
EPEAT Compliant
EPEAT Gold
ENERGY STAR Certified
Yes
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 1 year - on-site
Dimensions & Weight
Width
27 cm
Depth
9.5 cm
Height
30.8 cm
Weight
4.2 kg
Dimensions & Weight (Shipping)
Shipping Width
39.4 cm
Shipping Depth
49.9 cm
Shipping Height
20.5 cm
Shipping Weight
7.25 kg
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
10 - 90% (non-condensing)
