General
Type
Personal computer
Product Form Factor
Small form factor
Built-in Devices
Speaker
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Processor / Chipset
CPU
Intel Core i3 (10th Gen) 10100
Clock Speed
3.6 GHz
Max Turbo Speed
4.3 GHz
Number of Cores
Quad-Core
CPU Qty
1
Max CPU Qty
1
CPU Upgradability
Upgradable
Processor Main Features
Intel Turbo Boost Technology 2, Intel Smart Cache
Chipset Type
Intel Q470
Cache Memory
Installed Size
6 MB
Cache Per Processor
6 MB
RAM
Installed Size
8 GB / 64 GB (max)
Technology
DDR4 SDRAM - non-ECC
Effective Memory Speed
2666 MHz
Rated Memory Speed
2666 MHz
Memory Specification Compliance
PC4-21333
Form Factor
DIMM 288-pin
Slots
2 (Total) / 1 (empty)
Configuration Features
1 x 8 GB
Hard Drive
Type
SSD - M.2 2280
Capacity
1 x 256 GB
Interface Type
PCI Express 3.0
Features
NVM Express (NVMe)
Storage Controller
Type
1 x SATA
Controller Interface Type
SATA 6Gb/s
Optical Storage
Type
DVD-Writer - SATA
Card Reader
Type
5 in 1 card reader
Supported Flash Memory Cards
SD Memory Card, SDHC Memory Card, SDXC Memory Card, SDHC UHS-I Memory Card, SDHC UHS-II Memory Card
Monitor
Monitor Type
None.
Graphics Controller
Graphics Processor
Intel UHD Graphics 630 Dynamic Video Memory Technology
Video Interfaces
HDMI, DisplayPort
HDCP Compatible
Yes
Max Monitors Supported
3
Audio Output
Sound Output Mode
Stereo
Max Sampling Rate
192 kHz
Compliant Standards
High Definition Audio
Input Device
Type
Mouse, keyboard
Mouse
Technology
Optical
Interface
USB
Networking
Ethernet Controller
Intel I219-LM
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
SNMP 2
Features
Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), PXE 2.1 support
Compliant Standards
IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3az
Expansion / Connectivity
Bays
1 (total) / 0 (free) x external 5.25" Slim Line ¦ 1 (total) / 1 (free) x internal 2 x 2.5"/3.5" shared
Slots
1 (total) / 1 (free) x PCIe 3.0 x1 ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 ¦ 1 (total) / 0 (free) x M.2 Card - 2280 (x4 mode) ¦ 1 (total) / 1 (free) x M.2 Card - 2230 (x1 mode)
Interfaces
2 x USB 3.2 Gen 2 (2 in front) ¦ 4 x USB 2.0 (2 front, 2 rear) (two of them with wake functionality) ¦ 1 x HDMI ¦ 2 x DisplayPort ¦ 1 x headphones/microphone (1 in front) (CTIA and OMTP headset support) ¦ 1 x audio line-out ¦ 1 x LAN (Gigabit Ethernet) ¦ 3 x USB 3.1 Gen 1
Miscellaneous
Cables Included
Storage cable kit
Theft/Intrusion Protection
Security lock slot (cable lock sold separately), padlock loop
Security Slot Type
Kensington security slot
Compliant Standards
FCC Class B certified, ICES-003, CCC, RoHS, UL 60950-1, CSA C22.2 No. 60950-1-07, WEEE, KCC Class B, Common Criteria EAL4+, VCCI Class B, low halogen, UL 62368-1, CAN/CSA-C22.2 No. 62368-1-14
Power
Device Type
Power supply
Voltage Required
AC 120/230 V (50/60 Hz)
Power Provided
180 Watt
80 PLUS Certification
80 PLUS Gold
Efficiency
90% at 20% Load (230 VAC), 92% at 50% Load (230 VAC), 89% at 100% Load (230 VAC)
Power Factor Correction
Yes (active)
Operating System / Software
OS Provided
Windows 10 Pro 64-bit Edition
Software
HP Support Assistant, Windows Defender, HP Secure Erase, HP BIOS Configuration Utility (free download), HP Client Catalog, HP Setup Integrated OOBE, HP JumpStart, HP Noise Cancellation, HP System Software Manager (free download), HP Privacy Settings, HP Cloud Recovery, HP Client Security Manager Gen6, HP BIOSphere Gen6, HP Image Assistant Gen5, HP Desktop Support Utility, HP Manageability Integration Kit for Microsoft System Centre Configuration Manager Gen4 (free download)
Sustainability Information
ENERGY STAR Certified
Yes
Dimensions & Weight
Width
27 cm
Depth
30.3 cm
Height
9.5 cm
Weight
3.9 kg
Dimensions & Weight (Shipping)
Shipping Width
39.4 cm
Shipping Depth
20.5 cm
Shipping Height
49.9 cm
Shipping Weight
6.97 kg
Environmental Parameters
Min Operating Temperature
5 °C
Max Operating Temperature
35 °C
Humidity Range Operating
5 - 90% (non-condensing)
