General
Platform Technology
Intel vPro Platform
Type
Personal computer
Product Form Factor
All-in-one - with Fixed Height Tilt Stand
Built-in Devices
Stereo speakers
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Processor / Chipset
CPU
Intel Core i5 (10th Gen) 10500T
Clock Speed
2.3 GHz
Max Turbo Speed
3.8 GHz
Number of Cores
6-core
CPU Qty
1
Max CPU Qty
1
CPU Upgradability
Upgradable
Processor Main Features
Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache
Chipset Type
Intel Q470
Cache Memory
Installed Size
12 MB
Cache Per Processor
12 MB
RAM
Installed Size
8 GB / 64 GB (max)
Technology
DDR4 SDRAM
Effective Memory Speed
2666 MHz
Rated Memory Speed
2666 MHz
Form Factor
SO-DIMM 260-pin
Slots
2 (Total) / 1 (empty)
Configuration Features
1 x 8 GB
Hard Drive
Type
SSD - M.2 2280
Capacity
1 x 256 GB
Interface Type
PCI Express
Features
NVM Express (NVMe)
Storage Controller
Type
1 x SATA
Controller Interface Type
SATA 6Gb/s
Optical Storage
Type
DVD-Writer - SATA
Monitor
Monitor Type
LED - IPS
Diagonal Size
23.8"
Native Resolution
1920 x 1080 (Full HD)
Widescreen Display
Yes
Image Aspect Ratio
16:9
Colour Gamut
72% NTSC
Image Brightness
250 cd/m²
Monitor Features
Full HD anti-glare
Graphics Controller
Graphics Processor
Intel UHD Graphics 630 Dynamic Video Memory Technology
Video Interfaces
HDMI, DisplayPort
HDCP Compatible
Yes
Max Monitors Supported
3
Audio Output
Sound Output Mode
Stereo
Max Sampling Rate
192 kHz
Compliant Standards
High Definition Audio
Speakers Included
2 x right / left channel
Camera
Camera
Yes
Resolution (MP)
5 Megapixel
Features
Pull-up webcam
Input Device
Type
Mouse, keyboard
Keyboard
Keyboard Name
HP 320K
Interface
USB
Mouse
Technology
Optical
Interface
USB
Audio Input
Type
Dual array microphone
Networking
Interface (Bus) Type
M.2 Card
Ethernet Controller
Intel I219-LM
Wireless LAN Supported
Yes
Wireless NIC
Intel Wi-Fi 6 AX 201
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0
Remote Management Protocol
SNMP 2
Features
Wake on LAN (WoL), auto-uplink (auto MDI/MDI-X), PXE 2.1 support, dual stream (2x2)
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.1x, IEEE 802.11i, Wi-Fi CERTIFIED, IEEE 802.3az
Expansion / Connectivity
Bays
1 (total) / 1 (free) x internal 2.5" ¦ 1 (total) / 0 (free) x external 5.25" Slim Line
Slots
1 (total) / 0 (free) x M.2 Card - 2230 ¦ 1 (total) / 0 (free) x M.2 Card - 2230/2280
Interfaces
4 x USB 3.2 Gen 1 - Type A (two of them with wake functionality) ¦ 1 x USB 3.2 Gen 2 - Type A (1 side) ¦ 1 x USB-C 3.2 Gen 2 (1 side) ¦ 1 x DisplayPort ¦ 1 x headphones/microphone (CTIA and OMTP headset support) ¦ 1 x LAN (Gigabit Ethernet) ¦ 2 x HDMI
Miscellaneous
Theft/Intrusion Protection
Security lock slot (cable lock sold separately)
Security Slot Type
Kensington security slot
Compliant Standards
RoHS, WEEE, Common Criteria EAL4+, low halogen
Power
Device Type
Power adapter
Voltage Required
AC 90-264 V (50/60 Hz)
Power Provided
90 Watt
Efficiency
88% (115VAC) / 89% (230VAC)
Power Factor Correction
Yes (active)
Operating System / Software
OS Provided
Windows 10 Pro 64-bit Edition
Software
HP Support Assistant, HP Hotkey Support, Windows Defender, HP Secure Erase, HP BIOS Config Utility, HP Setup Integrated OOBE, HP JumpStart, HP Noise Cancellation, HP System Software Manager, HP Privacy Settings, HP Cloud Recovery, HP Sure Sense, HP Client Security Manager Gen6, HP Manageability & Integration Kit Gen4, HP BIOSphere Gen6, HP Image Assistant Gen5
Sustainability Information
ENERGY STAR Certified
Yes
Dimensions & Weight
Dimensions & Weight Details
53.93 cm - 15.65 cm - 40.32 cm - 6.59 kg - with stand
Width
53.93 cm
Depth
15.65 cm
Height
40.32 cm
Weight
6.59 kg
Dimensions & Weight (Shipping)
Shipping Width
66 cm
Shipping Depth
24.5 cm
Shipping Height
46.2 cm
Shipping Weight
10.42 kg
Environmental Parameters
Min Operating Temperature
5 °C
Max Operating Temperature
35 °C
Humidity Range Operating
5 - 90% (non-condensing)
