General
Type
Thin client
Product Form Factor
Small form factor
Built-in Devices
Speaker
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Language: English / region: United Kingdom
Processor / Chipset
CPU
AMD Ryzen Embedded R1505G
Clock Speed
2.4 GHz
Max Turbo Speed
3.3 GHz
Number of Cores
Dual-Core
CPU Qty
1
Max CPU Qty
1
Cache Memory
Installed Size
L3 Cache - 4 MB
Cache Per Processor
4 MB
RAM
Installed Size
8 GB / 32 GB (max)
Technology
DDR4 SDRAM
Effective Memory Speed
2400 MHz
Rated Memory Speed
2400 MHz
Form Factor
SO-DIMM 260-pin
Slots
2 (Total) / 1 (empty)
Features
Dual channel memory architecture
Configuration Features
1 x 8 GB
Hard Drive
Type
Flash - M.2
Capacity
1 x 32 GB
Optical Storage
Type
No optical drive
Monitor
Monitor Type
None.
Graphics Controller
Graphics Processor
AMD Radeon Vega 3
Video Interfaces
DisplayPort
Max Monitors Supported
3
Input Device
Type
Mouse, keyboard
Keyboard
Keyboard Name
HP Business Slim Keyboard
Interface
USB
Localization & Layout
UK
Mouse
Technology
Optical
Interface
USB
Networking
Ethernet Controller
Realtek RTL8111EPH-CG
Wireless LAN Supported
Yes
Wireless NIC
Intel Dual Band Wireless-AC 9260
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0
Features
Wake on LAN (WoL), PXE support
Compliant Standards
IEEE 802.11ac, Bluetooth 5.0
Expansion / Connectivity
Slots
1 (total) / 0 (free) x M.2 Card
Interfaces
3 x DisplayPort ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x headphones/microphone ¦ 2 x USB 2.0 ¦ 3 x USB 3.1 Gen 1 ¦ 1 x USB 3.1 Gen 2 ¦ 1 x USB-C 3.1 Gen 2 ¦ 1 x audio line-out/line-in
Miscellaneous
Theft/Intrusion Protection
Security lock slot (cable lock sold separately)
Security Slot Type
Kensington security slot
Compliant Standards
FCC Class B certified, UL, BSMI, GS, CB, CCC, EMC, RoHS, ICES Class B, WEEE, EN 60601-1-2, KCC Class B, ERP, CECP, VCCI Class B, CISPR Class B, SEPA, HP GSE, EN, CNS
Power
Device Type
Power adapter
Voltage Required
AC 120/230 V (50/60 Hz)
Power Provided
45 Watt
Operating System / Software
OS Provided
Windows 10 IoT Enterprise for Thin Clients 64-bit Edition English
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years
Dimensions & Weight
Width
3.5 cm
Depth
19.6 cm
Height
19.6 cm
Weight
994.5 g
Dimensions & Weight (Shipping)
Shipping Weight
2.878 kg
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% (non-condensing)
