General
Type
Thin client
Product Form Factor
Small form factor
Built-in Devices
Speaker
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Language: English / region: United Kingdom
Processor / Chipset
CPU
AMD Ryzen Embedded V1756B
Clock Speed
3.25 GHz
Max Turbo Speed
3.6 GHz
Number of Cores
Quad-Core
CPU Qty
1
Max CPU Qty
1
CPU Upgradability
Not upgradable
RAM
Installed Size
8 GB
Technology
DDR4 SDRAM
Effective Memory Speed
2400 MHz
Rated Memory Speed
2400 MHz
Form Factor
SO-DIMM 260-pin
Slots
2 (Total) / 0 (empty)
Features
Dual channel memory architecture
Configuration Features
2 x 4 GB
Hard Drive
Type
Flash - M.2
Capacity
1 x 32 GB
Optical Storage
Type
No optical drive
Monitor
Monitor Type
None.
Graphics Controller
Graphics Processor
AMD Radeon Vega 8
Video Interfaces
DisplayPort
Max Monitors Supported
4
Networking
Ethernet Controller
Realtek RTL8111EPH-CG
Wireless LAN Supported
Yes
Wireless NIC
Intel Wireless-AC 9260
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0
Remote Management Protocol
SNMP
Features
Wake on LAN (WoL)
Compliant Standards
IEEE 802.1p, IEEE 802.1x, IEEE 802.11ac
Expansion / Connectivity
Slots
2 (total) / 1 (free) x M.2 Card ¦ 1 (total) / 1 (free) x PCIe x16 - half-height (x8 mode)
Interfaces
2 x USB 2.0 ¦ 3 x USB 3.1 Gen 1 (1 front, 2 rear) ¦ 4 x DisplayPort ¦ 1 x USB 3.1 Gen 2 ¦ 1 x USB-C 3.1 Gen 2 ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x headphones/microphone
Miscellaneous
Theft/Intrusion Protection
Security lock slot (cable lock sold separately)
Security Slot Type
Kensington security slot
Compliant Standards
FCC Class B certified, UL, BSMI, GS, CCC, ICES Class B, KCC Class B, CECP, RoHS2, VCCI Class B, CISPR Class B, SEPA, low halogen, HP GSE
Power
Device Type
Power adapter
Voltage Required
AC 120/230 V (50/60 Hz)
Power Provided
90 Watt
Operating System / Software
OS Provided
Windows 10 IoT Enterprise for Thin Clients 64-bit Edition English
Software
Microsoft Internet Explorer, Citrix ICA, Microsoft Windows Media Player, Microsoft Firewall, HP Remote Graphics Software, HP Device Manager, LogOn Manager, VMware Horizon View, Citrix HDX, Microsoft RemoteFX, Unified Write Filter, HP CIK for Microsoft SCCM, HP ThinUpdate, HP Easy Shell, Microsoft SCCM/EDM-agent, Citrix Workspace Suite, HP Write Manager
Environmental Standards
ENERGY STAR Certified
Yes
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years
Dimensions & Weight
Width
5 cm
Depth
21 cm
Height
21 cm
Weight
1.323 kg
Dimensions & Weight (Shipping)
Shipping Weight
3.798 kg
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
40 °C
Humidity Range Operating
10 - 90% (non-condensing)
