General
Platform Technology
Intel vPro Platform
Type
Workstation
Product Form Factor
Tower
Built-in Devices
Speaker
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Language: English / region: United Kingdom
Processor / Chipset
CPU
Intel Core i7 (10th Gen) 10700
Clock Speed
2.9 GHz
Max Turbo Speed
4.8 GHz
Number of Cores
8-core
CPU Qty
1
Max CPU Qty
1
CPU Upgradability
Upgradable
Processor Main Features
Intel Turbo Boost Technology 3
Chipset Type
Intel Q470
Cache Memory
Installed Size
L3 Cache - 16 MB
Cache Per Processor
16 MB
RAM
Installed Size
16 GB / 128 GB (max)
Technology
DDR4 SDRAM - non-ECC
Effective Memory Speed
2666 MHz
Rated Memory Speed
2666 MHz
Form Factor
DIMM 288-pin
Slots
4 (Total) / 2 (empty)
Features
Unbuffered
Configuration Features
2 x 8 GB
Hard Drive
Type
SSD - M.2 2280
Capacity
1 x 512 GB
Interface Type
PCI Express 3.0 x4
Features
NVM Express (NVMe)
Storage Controller
Type
1 x SATA
Channel Qty
4
Optical Storage
Type
DVD-Writer - SATA
Monitor
Monitor Type
None.
Graphics Controller
Interface Type
PCIe 3.0 x16
Multi-GPU Configuration
1 single GPU card / integrated GPU
Graphics Processor
NVIDIA GeForce RTX 2060 SUPER / Intel UHD Graphics 630
Video Memory
8 GB GDDR6 SDRAM
Video Interfaces
DVI, HDMI, DisplayPort
HDCP Compatible
Yes
Audio Output
Sound Output Mode
Stereo
Max Sampling Rate
192 kHz
Compliant Standards
High Definition Audio
Input Device
Type
Mouse, keyboard
Keyboard
Interface
USB
Localization & Layout
UK
Mouse
Technology
Optical
Interface
USB
Networking
Ethernet Controller
Intel I219-LM
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
SNMP 2
Features
Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), PXE 2.1 support
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3az
Expansion / Connectivity
Bays
1 (total) / 0 (free) x external 5.25" Slim Line ¦ 1 (total) / 1 (free) x external 5.25" ¦ 1 (total) / 1 (free) x internal 2.5" ¦ 2 (total) / 2 (free) x internal 2.5" / 3.5" shared
Slots
1 (total) / 0 (free) x PCIe 3.0 x16 ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 (x4 mode) ¦ 2 (total) / 2 (free) x PCIe 3.0 x1 ¦ 1 (total) / 1 (free) x M.2 Card - 2230 (for wireless module) ¦ 2 (total) / 1 (free) x M.2 Card - 2230/2280 (for internal storage)
Interfaces
1 x headphones/microphone (1 in front) (CTIA and OMTP headset support) ¦ 4 x USB 3.2 Gen 1 (2 front, 2 rear) (one of them is fast-charging) ¦ 4 x USB 3.2 Gen 2 (2 front, 2 rear) ¦ 1 x USB-C 3.2 Gen 2x2 (1 in front) (charging) ¦ 1 x audio line-out (for powered audio devices) ¦ 3 x DisplayPort ¦ 2 x USB 2.0 (wake functionality) ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x HDMI ¦ 1 x DVI-D
Miscellaneous
Theft/Intrusion Protection
Security lock slot (cable lock sold separately), padlock loop
Security Slot Type
Kensington security slot
Compliant Standards
FCC Class B certified, ICES-003, CCC, RoHS, UL 60950-1, CSA C22.2 No. 60950-1-07, WEEE, KCC Class B, Common Criteria EAL4+, CECP, VCCI Class B, SEPA, low halogen, UL 62368-1, CAN/CSA-C22.2 No. 62368-1-14
Power
Device Type
Power supply
Voltage Required
AC 120/230 V (50/60 Hz)
Power Provided
550 Watt
80 PLUS Certification
80 PLUS Platinum
Efficiency
90% at 20% Load (115 VAC), 92% at 50% Load (115 VAC), 89% at 100% Load (115 VAC), 91% at 20% Load (230 VAC), 93% at 50% Load (230 VAC), 90% at 100% Load (230 VAC)
Power Factor Correction
Yes (active)
Operating System / Software
OS Provided
Windows 10 Pro 64-bit Edition English
Software
HP Support Assistant, Windows Defender, HP Secure Erase, HP Setup Integrated OOBE, HP JumpStart, HP PC Hardware Diagnostics, HP Noise Cancellation, HP Notifications, HP Sure Click, HP BIOSphere Gen5, HP Privacy Settings, HP Sure Sense, HP QuickDrop, HP Sure Recover Gen3, HP SureStart Gen6, HP Sure Run Gen3, HP DriveLock, HP Wake on WLAN, HP Desktop Support Utility, HP Client Security Suite Gen6
Environmental Standards
TCO Certified
TCO Certified Desktops 8
ENERGY STAR Certified
Yes
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site
Dimensions & Weight
Width
16.8 cm
Depth
37 cm
Height
30.8 cm
Weight
9.86 kg
Dimensions & Weight (Shipping)
Shipping Width
29.9 cm
Shipping Depth
47.8 cm
Shipping Height
51.7 cm
Shipping Weight
11.34 kg
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
10 - 90% (non-condensing)
