General
Platform Technology
Intel vPro Platform
Type
Workstation
Product Form Factor
Small form factor
Built-in Devices
Speaker
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Colour
Black
Localisation
Language: English / region: United Kingdom
Processor / Chipset
CPU
Intel Core i7 (10th Gen) 10700
Clock Speed
2.9 GHz
Max Turbo Speed
4.8 GHz
Number of Cores
8-core
CPU Qty
1
Max CPU Qty
1
CPU Upgradability
Upgradable
Processor Main Features
Intel Turbo Boost Technology
CPU Socket
FCLGA1200 Socket
Chipset Type
Intel W480
Cache Memory
Installed Size
L3 Cache - 16 MB
Cache Per Processor
16 MB
RAM
Installed Size
16 GB / 128 GB (max)
Technology
DDR4 SDRAM - non-ECC
Effective Memory Speed
2933 MHz
Rated Memory Speed
3200 MHz
Form Factor
DIMM 288-pin
Slots
4 (Total) / 2 (empty)
Configuration Features
2 x 8 GB
Hard Drive
Type
SSD - M.2 2280
Capacity
1 x 512 GB
Interface Type
PCI Express 3.0 x4
Features
HP Z Turbo Drive, triple-level cell (TLC)
Storage Controller
Type
1 x SATA
Controller Interface Type
SATA 6Gb/s
Channel Qty
4
RAID Level
RAID 0, RAID 1
Optical Storage
Type
No optical drive
Monitor
Monitor Type
None.
Graphics Controller
Interface Type
PCIe 3.0 x16
Multi-GPU Configuration
1 single GPU card / integrated GPU
Graphics Processor
NVIDIA T600 / Intel UHD Graphics 630
Video Memory
4 GB GDDR6 SDRAM
Video Interfaces
DisplayPort
Audio Output
Compliant Standards
High Definition Audio
Input Device
Type
Mouse, keyboard
Keyboard
Interface
USB
Localization & Layout
UK
Networking
Ethernet Controller
Intel I219-LM
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Features
Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), PXE 2.1 support, Intel Active Management Technology (AMT) 12
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1as, IEEE 802.3az
Expansion / Connectivity
Bays
1 (total) / 1 (free) x internal 2.5" ¦ 1 (total) / 1 (free) x external 5.25" Slim Line ¦ 1 (total) / 1 (free) x external 3.5" ¦ 1 (total) / 1 (free) x internal 3.5"
Slots
1 (total) / 1 (free) x M.2 Card - 2230 (PCIe 3.0 x1 mode and Intel CNVi wireless module) ¦ 2 (total) / 1 (free) x M.2 Card - 2280 (x4 mode) ¦ 1 (total) / 0 (free) x PCIe 3.0 x16 - half-length, low-profile ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - half-length, low-profile (x4 mode) ¦ 2 (total) / 2 (free) x PCIe 3.0 x1 - half-length, low-profile (open ended) ¦ 1 (total) / 1 (free) x Flex I/O
Interfaces
2 x USB 3.2 Gen 1 (2 in front) (one of them is charging) ¦ 1 x headphones/microphone (1 in front) (CTIA and OMTP headset support) ¦ 1 x LAN (Gigabit Ethernet) ¦ 2 x DisplayPort 1.4 ¦ 4 x USB 3.2 Gen 2 - Type A (2 front, 2 rear) ¦ 2 x USB 2.0 ¦ 1 x audio line-out ¦ 1 x USB-C 3.2 Gen 2 (1 in front) (charging) ¦ 2 x USB 3.2 Gen 1 - Type A ¦ 4 x Mini DisplayPort
Miscellaneous
Theft/Intrusion Protection
Security lock slot (cable lock sold separately)
Security Slot Type
Kensington security slot
Compliant Standards
ACPI, CCC, RoHS, WEEE, Common Criteria EAL4+, CECP
Power
Device Type
Power supply
Voltage Required
AC 90-269 V (50/60 Hz)
Power Provided
450 Watt
Efficiency
90%
Power Factor Correction
Yes (active)
Operating System / Software
OS Provided
Windows 10 Pro 64-bit Edition (available through downgrade rights from Windows 11 Pro) + Windows 11 Pro Licence - English
Software
HP ZCentral Remote Boost 2020
Environmental Standards
TCO Certified
TCO Certified Desktops 8
EPEAT Compliant
EPEAT Gold
ENERGY STAR Certified
Yes
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site
Dimensions & Weight
Width
33.8 cm
Depth
30.8 cm
Height
10 cm
Weight
5.4 kg
Dimensions & Weight (Shipping)
Shipping Width
22.8 cm
Shipping Depth
39.9 cm
Shipping Height
49.9 cm
Environmental Parameters
Min Operating Temperature
5 °C
Max Operating Temperature
35 °C
Humidity Range Operating
10 - 85% (non-condensing)
