General
Platform Technology
Intel vPro Platform
Type
Workstation
Product Form Factor
Tower - 4U
Built-in Devices
Speaker
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Colour
Black
Localisation
Language: English / region: United Kingdom
Processor / Chipset
CPU
Intel Core i7 (10th Gen) 10700K
Clock Speed
3.8 GHz
Max Turbo Speed
5.1 GHz
Number of Cores
8-core
CPU Qty
1
Max CPU Qty
1
CPU Upgradability
Upgradable
Processor Main Features
Hyper-Threading Technology, Intel Turbo Boost Max 3.0
CPU Socket
FCLGA1200 Socket
Chipset Type
Intel W480
Cache Memory
Installed Size
16 MB
Cache Per Processor
16 MB
RAM
Installed Size
32 GB / 128 GB (max)
Technology
DDR4 SDRAM - non-ECC
Effective Memory Speed
2933 MHz
Rated Memory Speed
3200 MHz
Form Factor
DIMM 288-pin
Slots
4 (Total) / 2 (empty)
Features
Unbuffered
Configuration Features
2 x 16 GB
Hard Drive
Type
SSD - M.2 2280
Capacity
1 x 1 TB
Interface Type
PCI Express 3.0 x4
SSD Endurance
300 TB
Features
HP Z Turbo Drive, NVM Express (NVMe), triple-level cell (TLC), 3D NAND Technology
Storage Controller
Type
1 x SATA
Controller Interface Type
SATA 6Gb/s
Channel Qty
4
RAID Level
RAID 0, RAID 1
Optical Storage
Type
No optical drive
Monitor
Monitor Type
None.
Graphics Controller
Interface Type
PCIe x16
Multi-GPU Configuration
1 single GPU card / integrated GPU
Graphics Processor
NVIDIA RTX A2000 / Intel UHD Graphics 630
Video Memory
6 GB GDDR6 SDRAM
Video Interfaces
DisplayPort
Audio Output
Compliant Standards
High Definition Audio
Input Device
Type
Mouse, keyboard
Keyboard
Interface
USB
Localization & Layout
UK
Networking
Ethernet Controller
Intel I219-LM
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Features
Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), PXE 2.1 support, Intel Active Management Technology (AMT) 12
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1as, IEEE 802.3az
Expansion / Connectivity
Bays
1 (total) / 1 (free) x external 5.25" ¦ 1 (total) / 1 (free) x external 5.25" Slim Line ¦ 2 (total) / 2 (free) x internal 3.5" ¦ 1 (total) / 1 (free) x internal 2.5"
Slots
1 (total) / 0 (free) x PCIe 3.0 x16 - full-length, full-height ¦ 2 (total) / 2 (free) x PCIe 3.0 x4 - full-length, full-height (x1 mode, open ended) ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - full-length, full-height (x4 mode) ¦ 2 (total) / 1 (free) x M.2 Card - 2280 (x4 mode) ¦ 1 (total) / 1 (free) x M.2 Card - 2230 (PCIe 3.0 x1 mode and Intel CNVi wireless module)
Interfaces
2 x DisplayPort 1.4 ¦ 2 x USB 3.2 Gen 1 (2 in front) (one of them is charging) ¦ 1 x LAN (Gigabit Ethernet) ¦ 4 x USB 3.2 Gen 2 (2 front, 2 rear) ¦ 1 x audio line-in ¦ 1 x audio line-out ¦ 1 x headphones/microphone (1 in front) (CTIA and OMTP headset support) ¦ 2 x USB 2.0 ¦ 2 x USB 3.2 Gen 1 ¦ 4 x Mini DisplayPort
Miscellaneous
Included Accessories
HP Tower Card Holder/Blower Kit
Theft/Intrusion Protection
Security lock slot (cable lock sold separately)
Security Slot Type
Kensington security slot
Compliant Standards
ACPI, RoHS
Power
Device Type
Power supply
Voltage Required
AC 90-269 V (50/60 Hz)
Power Provided
700 Watt
Efficiency
92%
Power Factor Correction
Yes (active)
Operating System / Software
OS Provided
Windows 10 Pro 64-bit Edition (available through downgrade rights from Windows 11 Pro) + Windows 11 Pro Licence - English
Software
HP Remote Graphics Software, HP Support Assistant, Windows Defender, HP PC Hardware Diagnostics UEFI, HP Secure Erase, HP BIOS Config Utility, HP Image Assistant, HP Documentation, HP PC Hardware Diagnostics, HP System Software Manager, HP Notifications, HP Performance Advisor (free download), HP Manageability Integration Kit Gen4 (free dowload), HP Client Security Manager Gen6, HP BIOSphere Gen6, HP Wake on WLAN, HP Desktop Support Utility, HP ZCentral Remote Boost (free download), HP Smart Support (free download)
Environmental Standards
TCO Certified
TCO Certified Desktops 8, TCO Certified Displays 9
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site
Dimensions & Weight
Width
16.9 cm
Depth
38.5 cm
Height
35.6 cm
Weight
7 kg
Dimensions & Weight (Shipping)
Shipping Width
29.5 cm
Shipping Depth
49 cm
Shipping Height
51.8 cm
Environmental Parameters
Min Operating Temperature
5 °C
Max Operating Temperature
35 °C
Humidity Range Operating
10 - 85% (non-condensing)
