General
Platform Technology
Intel vPro Platform
Type
Workstation
Product Form Factor
Mini
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Language: English / region: United Kingdom
Processor / Chipset
CPU
Intel Core i7 (12th Gen) 12700K
Clock Speed
3.6 GHz
Max Turbo Speed
5 GHz
Number of Cores
12-core
CPU Qty
1
Max CPU Qty
1
CPU Upgradability
Upgradable
Processor Main Features
Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache, Intel Turbo Boost Max 3.0
CPU Socket
LGA1700 Socket
Chipset Type
Intel W680
Cache Memory
Installed Size
L3 Cache - 25 MB
Cache Per Processor
25 MB
RAM
Installed Size
32 GB (installed) / 64 GB (max)
Technology
DDR5 SDRAM - non-ECC
Effective Memory Speed
4800 MHz
Rated Memory Speed
4800 MHz
Form Factor
SO-DIMM 260-pin
Slots
2 (Total) / 1 (empty)
Features
Dual channel memory architecture
Configuration Features
1 x 32 GB
Hard Drive
Type
SSD - M.2 2280
Capacity
1 x 1 TB
Interface Type
PCI Express 4.0 x4
Features
HP Z Turbo Drive, NVM Express (NVMe), triple-level cell (TLC)
Storage Controller
Type
1 x SATA/NVMe
Controller Interface Type
SATA 6Gb/s / PCIe 4.0 x4 (NVMe)
RAID Level
RAID 0, RAID 1
Optical Storage
Type
No optical drive
Monitor
Monitor Type
None.
Graphics Controller
Interface Type
PCIe 4.0 x16
Multi-GPU Configuration
1 single GPU card / integrated GPU
Graphics Processor
NVIDIA RTX A2000 / Intel UHD Graphics 770
Video Memory
12 GB GDDR6 SDRAM
Video Interfaces
DisplayPort
Audio Output
Compliant Standards
High Definition Audio
Input Device
Type
Mouse, keyboard
Keyboard
Keyboard Name
HP 320K
Interface
USB
Localization & Layout
UK
Mouse
Mouse Name
HP 320M
Interface
USB
Networking
Interface (Bus) Type
M.2 2230 (CNVio2)
Ethernet Controller
Intel I219-LM
Wireless LAN Supported
Yes
Wireless NIC
Intel Wi-Fi 6E AX 211
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.2, IEEE 802.11ax (Wi-Fi 6E)
Features
Wake on LAN (WoL), auto-uplink (auto MDI/MDI-X), PXE 2.1 support, Intel Active Management Technology (AMT) 16
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1as, IEEE 802.3az
Expansion / Connectivity
Slots
1 (total) / 0 (free) x PCIe 4.0 x16 ¦ 2 (total) / 1 (free) x M.2 Card - 2280 (PCIe 4.0 x4 mode) ¦ 1 (total) / 0 (free) x M.2 Card (for Intel CNVi wireless module)
Interfaces
1 x headphones/microphone (CTIA and OMTP headset support) ¦ 4 x USB 3.2 Gen 2 (charging) ¦ 2 x USB-C 3.2 Gen 2x2 (charging) ¦ 2 x DisplayPort 1.4 ¦ 1 x LAN (Gigabit Ethernet) - RJ-45 ¦ 4 x Mini DisplayPort 1.4 ¦ 1 x DisplayPort 2.0
Miscellaneous
Included Accessories
Vertical stand
Cables Included
Mini DisplayPort-DisplayPort adapter (4 pcs.)
Theft/Intrusion Protection
Security lock slot (cable lock sold separately)
Security Slot Type
Kensington security slot
Compliant Standards
RoHS, FIPS 140-2, WEEE, CECP, low halogen
Power
Device Type
Power adapter
Power Device Name
HP Smart AC Adapter
Voltage Required
AC 115/230 V (50/60 Hz)
Power Provided
280 Watt
Efficiency
89%
Power Factor Correction
Yes
Operating System / Software
OS Provided
Windows 10 Pro 64-bit Edition (available through downgrade rights from Windows 11 Pro) + Windows 11 Pro Licence - English
Software
HP Support Assistant, HP Performance Advisor, Windows Defender, HP PC Hardware Diagnostics UEFI, HP Secure Erase, HP BIOS Config Utility, HP Image Assistant, HP Documentation, HP PC Hardware Diagnostics, HP System Software Manager, HP Notifications, Power On Authentication, HP Privacy Settings, HP Cloud Recovery, HP QuickDrop, HP BIOSphere Gen6, HP Desktop Support Utility, myHP, Touchpoint Customiser for Commercial, HP Easy Clean
Sustainability Information
TCO Certified
TCO Certified Desktops 9
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 5 years - on-site
Dimensions & Weight
Width
21.1 cm
Depth
21.8 cm
Height
6.9 cm
Weight
2.4 kg
Dimensions & Weight (Shipping)
Shipping Width
17 cm
Shipping Depth
49.9 cm
Shipping Height
29.8 cm
Shipping Weight
4.8 kg
Environmental Parameters
Min Operating Temperature
5 °C
Max Operating Temperature
35 °C
Humidity Range Operating
10 - 85% (non-condensing)
