General
Platform Technology
Intel vPro Platform
Type
Workstation
Product Form Factor
SFF
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Colour
Black
Localisation
Language: English / region: United Kingdom
Bundled with
HP Wolf Pro Security Edition (1 year)
Processor / Chipset
CPU
Intel Core i9 (12th Gen) 12900
Clock Speed
2.4 GHz
Max Turbo Speed
5.1 GHz
Number of Cores
16-core
CPU Qty
1
Max CPU Qty
1
CPU Upgradability
Upgradable
Processor Main Features
Hyper-Threading Technology, Intel Turbo Boost Technology 3
CPU Socket
LGA1700 Socket
Chipset Type
Intel W680
Cache Memory
Installed Size
L3 Cache - 30 MB
Cache Per Processor
30 MB
RAM
Installed Size
32 GB (installed) / 128 GB (max)
Technology
DDR5 SDRAM - non-ECC
Effective Memory Speed
4800 MHz
Rated Memory Speed
4800 MHz
Form Factor
DIMM 288-pin
Slots
4 (Total) / 2 (empty)
Features
Dual channel memory architecture
Configuration Features
2 x 16 GB
Hard Drive
Type
SSD - M.2 2280
Capacity
1 x 1 TB
Interface Type
PCI Express 4.0 x4
Features
HP Z Turbo Drive, NVM Express (NVMe), triple-level cell (TLC)
Storage Controller
Type
1 x SATA/NVMe
Controller Interface Type
SATA 6Gb/s / PCIe 4.0 x4 (NVMe)
Channel Qty
4
RAID Level
RAID 0, RAID 1
Optical Storage
Type
No optical drive
Monitor
Monitor Type
None.
Graphics Controller
Interface Type
PCIe 4.0 x16
Multi-GPU Configuration
1 single GPU card / integrated GPU
Graphics Processor
NVIDIA RTX A4000 / Intel UHD Graphics 770
Video Memory
16 GB GDDR6 SDRAM
Video Interfaces
DisplayPort
Audio Output
Compliant Standards
High Definition Audio
Input Device
Type
Mouse, keyboard
Keyboard
Keyboard Name
HP 320K
Interface
USB
Localization & Layout
UK
Mouse
Mouse Name
HP 320M
Interface
USB
Networking
Ethernet Controller
Intel I219-LM
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Features
Wake on LAN (WoL), auto-uplink (auto MDI/MDI-X), PXE 2.1 support, Intel Active Management Technology (AMT) 16
Compliant Standards
IEEE 802.1Q, IEEE 802.1p, IEEE 802.1as, IEEE 802.3az
Expansion / Connectivity
Bays
1 (total) / 1 (free) x 3.5" ¦ 1 (total) / 1 (free) x external 5.25" Slim Line ¦ 1 (total) / 1 (free) x internal 3.5"
Slots
1 (total) / 0 (free) x PCIe 4.0 x16 ¦ 1 (total) / 1 (free) x PCIe 3.0 x4 ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 (PCIe 3.0 x4 mode) ¦ 1 (total) / 1 (free) x PCIe 3.0 x1 ¦ 3 (total) / 2 (free) x M.2 Card - 2280 (PCIe 4.0 x4 mode) ¦ 1 (total) / 1 (free) x M.2 Card - 2230 (PCIe 3.0 x1 mode and Intel CNVi wireless module)
Interfaces
1 x headphones/microphone (1 in front) (CTIA and OMTP headset support) ¦ 4 x USB 3.2 Gen 2 (4 in front) (one of them is charging) ¦ 1 x USB-C 3.2 Gen 2x2 (1 in front) (charging) ¦ 1 x audio line-out ¦ 2 x DisplayPort 1.4 ¦ 3 x USB 2.0 ¦ 3 x USB 3.2 Gen 1 ¦ 1 x LAN (Gigabit Ethernet) - RJ-45
Miscellaneous
Theft/Intrusion Protection
Security lock slot (cable lock sold separately), padlock loop
Security Slot Type
Kensington security slot
Compliant Standards
RoHS, FIPS 140-2, WEEE, CECP, low halogen
Power
Device Type
Power supply
Voltage Required
AC 90-269 V (50/60 Hz)
Power Provided
550 Watt
Efficiency
92%
Power Factor Correction
Yes (active)
Operating System / Software
OS Provided
Windows 10 Pro for Workstations 64-bit Edition (available through downgrade rights from Windows 11 Pro for Workstations) + Windows 11 Pro for Workstations Licence - English
Software
HP Support Assistant, HP Performance Advisor, Windows Defender, HP PC Hardware Diagnostics UEFI, HP Secure Erase, HP Image Assistant, HP Documentation, HP PC Hardware Diagnostics, HP System Software Manager, HP Notifications, HP Sure Click, Power On Authentication, HP Privacy Settings, HP Cloud Recovery, HP Sure Sense, HP Sure Admin, HP QuickDrop, HP BIOSphere Gen6, HP Desktop Support Utility, myHP, Touchpoint Customiser for Commercial, HP Sure Recover Gen4, HP SureStart Gen7, HP Easy Clean, HP Client Security Suite Gen7, HP Wolf Security for Business, HP Sure Run Gen5, HP UWP Pack
Sustainability Information
TCO Certified
TCO Certified Desktops 9
EPEAT Compliant
EPEAT Gold
ENERGY STAR Certified
Yes
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site
Dimensions & Weight
Width
38.4 cm
Depth
30.8 cm
Height
10 cm
Weight
5 kg
Dimensions & Weight (Shipping)
Shipping Width
39.9 cm
Shipping Depth
49.9 cm
Shipping Height
22.8 cm
Environmental Parameters
Min Operating Temperature
5 °C
Max Operating Temperature
35 °C
Humidity Range Operating
10 - 85% (non-condensing)
