General
Device Type
Switch - L3 - Managed
Enclosure Type
Rack-mountable 6U
Subtype
100 Gigabit Ethernet
Performance
Switching capacity: 28.8 Tbps ¦ Throughput: 14.4 Bpps
Routing Protocol
OSPF, EGP, RIP, BGP-4, IS-IS, RIP-1, RIP-2, BGP, IGMPv2, IGMP, VRRP, OSPFv2, PIM-SM, PIM-DM, IGMPv3, GRE, OSPFv3, PIM-SSM, Bidirectional PIM, MSDP, static IPv4 routing, static IPv6 routing, ECMP, policy-based routing (PBR), RIPng, MLDv2, MLD, BGP-4+, MPLS, Bidirectional Forwarding Detection (BFD), CIDR, BGP for IPv6, BGP+
Remote Management Protocol
SNMP 1, SNMP 2, RMON 1, RMON 2, SNMP, RMON 3, RMON 9, RMON, Telnet, SNMP 3, HTTP, TFTP, SSH, SSH-2
Encryption Algorithm
MD5, AES, IKE, TLS
Authentication Method
Secure Shell (SSH), RADIUS, PAP, CHAP, TACACS+, Secure Shell v.2 (SSH2), Extensible Authentication Protocol (EAP)
Features
Flow control, NAT support, VPN support, ARP support, VLAN support, IGMP snooping, IPv6 support, Link Fault Signaling (LFS), Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Virtual Route Redundancy Protocol (VRRP) support, Multiple Spanning Tree Protocol (MSTP) support, tunnelling, Data Center Bridging Exchange (DCBX) support, IPSec Virtual Private Network (VPN), DHCP snooping, Access Control List (ACL) support, Quality of Service (QoS), RADIUS support, Per-VLAN Spanning Tree Plus (PVST+), Device Link Detection Protocol (DLDP) support, Bidirectional Forwarding Detection (BFD), Unicast Reverse Path Forwarding (URPF), IPv4 support, LACP support, LLDP support, DHCP relay, Link Aggregation Control Protocol (LACP), Port Security, Data Center Bridging (DCB), fan tray, DHCP client, Management Information Base (MIB), NTP time synchronisation, FCoE forwarding, Class of Service (CoS), UDP/IP offloading, Edge Virtual Bridging (EVB), Intelligent Resilient Framework Technology (IRF), Network Quality Analyzer (NQA), Multicast Source Discovery Protocol (MSDP), Multicast Border Gateway Protocol (MBGP), SNMP support, IP source guard
Compliant Standards
IEEE 802.3, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1ad, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.1ab (LLDP), IEEE 802.3ba, IEEE 802.1Qbb, IEEE 802.1Qaz
Processor
1 x MIPS MIPS64: 1.2 GHz
RAM
8 GB DDR3 SDRAM
Flash Memory
1 GB
Miscellaneous
Included Accessories
Rack mount kit
Compliant Standards
ETSI, CISPR 22 Class A, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, EN 61000-3-3, EN55024, EN55022 Class A, AS/NZS 60950-1, ICES-003 Class A, RoHS, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, EN 6100-3-2, AS/NZS, VCCI Class A, EN 50581, ETS 300 386, FDA 21CFR1040.10, EN 55022 Class A, FCC CFR47 Part 15 A, CAN/CSA-C22.2 No. 60950-1, EN 300386
