General
Device Type
Switch - 40 ports - L3 - Managed
Enclosure Type
Rack-mountable 1U
Subtype
10 Gigabit Ethernet
Ports
40 x 1 Gigabit / 10 Gigabit SFP+ + 2 x 40 Gigabit QSFP+ (uplink)
Performance
Throughput: 714.2 Mpps ¦ Routing/switching capacity: 960 Gbps
Capacity
IPv4 routing table entries: 128 ¦ IPv6 routing table entries: 128 ¦ Virtual interfaces (VLANs): 4096
MAC Address Table Size
128K entries
Jumbo Frame Support
Yes
Routing Protocol
RIP-1, RIP-2, IGMPv2, IGMP, IGMPv3, static IPv4 routing, static IPv6 routing
Remote Management Protocol
SNMP 1, Telnet, SNMP 3, SNMP 2c, TFTP, SSH, SSH-2, CLI
Authentication Method
Secure Shell (SSH), RADIUS, TACACS, TACACS+, Secure Shell v.2 (SSH2)
Features
Flow control, DHCP support, ARP support, IGMP snooping, port mirroring, Weighted Round Robin (WRR) queuing, SNTP support, Weighted Fair Queuing (WFQ), Weighted Random Early Detection (WRED), sFlow, PIM snooping, Multiple Spanning Tree Protocol (MSTP) support, Data Center Bridging Exchange (DCBX) support, priority-based flow control, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support, MLD snooping, Device Link Detection Protocol (DLDP) support, Equal-Cost Multipath (ECMP), LLDP support, Data Center Bridging (DCB), Management Information Base (MIB), NTP time synchronisation, Class of Service (CoS), Strict Priority (SP), Intelligent Resilient Framework Technology (IRF), FCoE support
Compliant Standards
IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ad, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.1ab (LLDP), IEEE 802.1Qbb, IEEE 802.3ag
RAM
2 GB SDRAM
Flash Memory
512 MB
Miscellaneous
Compliant Standards
GOST, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, NOM, EN 61000-3-3, EN55024, EN55022 Class A, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, EMC, ICES-003 Class A, EN 61000-4-5, EN 61000-4-11, RoHS, FCC CFR47 Part 15, EN 61000-4-8, UL 60950-1, IEC 60950-1, EN 60950-1, ANATEL, EN 60825-1, ANSI C63.4, EN 60825-2, VCCI Class A, AS/NZS CISPR 22, EN 300 386 V1.3.3, CAN/CSA-C22.2 No. 60950-1
Pricing Type
Factory integrated
