General
Type
Server
Product Form Factor
Rack-mountable - 2U
Embedded Security
Trusted Platform Module (TPM 1.2) Security Chip
Server Scalability
2-way
Hot-Swap Bays Qty
12
Processor / Chipset
CPU
No CPU
Max CPU Qty
2
CPU Upgradability
Upgradable
RAM
Installed Size
0 GB
Technology
DDR4 SDRAM
Form Factor
DIMM 288-pin
Slots
8 (Total) / 8 (empty)
RAM Supported
128 GB registered ¦ 256 GB Load-Reduced
Storage Controller
Type
1 x RAID - integrated
Controller Interface Type
SATA 6Gb/s
Storage Controller Name
HP Dynamic Smart Array B140i
Channel Qty
10
RAID Level
RAID 0, RAID 1, RAID 5, RAID 10
Optical Storage
Type
No optical drive
Monitor
Monitor Type
None.
Graphics Controller
Type
Integrated
Graphics Processor
Matrox G200eH2
Video Interfaces
VGA
Networking
Type
Integrated
Interface (Bus) Type
PCI Express 2.0 x2
Ethernet Ports
2 x Gigabit Ethernet
Ethernet Controller
HP NC361i
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller
Integrated Lights-Out 4
Features
Wake on LAN (WoL), PXE support
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1as, IEEE 802.3az
Expansion / Connectivity
Bays
12 (total) / 12 (free) x hot-swap 3.5" LFF
Slots
2 (total) / 2 (free) x CPU ¦ 8 (total) / 8 (free) x DIMM 288-pin ¦ 3 (total) / 3 (free) x PCIe 3.0 x16 - low-profile ¦ 2 (total) / 2 (free) x PCIe 3.0 x8 - low-profile ¦ 1 (total) / 1 (free) x microSD Card (internal)
Interfaces
2 x LAN (Gigabit Ethernet) ¦ 1 x VGA ¦ 1 x USB 2.0 (1 in front) ¦ 3 x USB 3.0 (2 rear, 1 internal)
Miscellaneous
Features
Administrator password, power-on password, UEFI BIOS
Compliant Standards
ACPI 2.0b, FCC Class A certified, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, FCC CFR47 Part 15, IEC 60950-1, EN 60950-1, WEEE, GB 4943, GB 9254, ASHRAE, CNS 13438, BSMI CNS 14336-1
Pricing Type
CTO
Power
Device Type
Power supply
Voltage Required
AC 120/230 V (50/60 Hz)
Power Provided
550 Watt
Operating System / Software
OS Certified
SUSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, Oracle Solaris
Manufacturer Warranty
Service & Support
Limited warranty - parts - 3 years
Dimensions & Weight
Width
44.55 cm
Depth
60.7 cm
Height
8.75 cm
Weight
16.59 kg
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% (non-condensing)
