General
Type
Server
Product Form Factor
Tower - 4.5U
Embedded Security
Trusted Platform Module (TPM 1.2) Security Chip
Server Scalability
1-way
Front Accessible Bays Qty
1
Hot-Swap Bays Qty
8
Processor / Chipset
CPU
No CPU
Max CPU Qty
1
CPU Upgradability
Upgradable
CPU Socket
LGA2011-v3 Socket
RAM
Installed Size
0 GB
Technology
DDR4 SDRAM - Advanced ECC
Form Factor
DIMM 288-pin
Slots
8 (Total) / 8 (empty)
Features
Online Spare Memory, HP SmartMemory
RAM Supported
PC4-17000 - 128 GB Load-Reduced ¦ PC4-17000 - 256 GB registered
Storage Controller
Type
1 x RAID - integrated
Controller Interface Type
SATA 6Gb/s
Storage Controller Name
HP Dynamic Smart Array B140i
Channel Qty
10
RAID Level
RAID 0, RAID 1, RAID 5, RAID 10
Optical Storage
Type
No optical drive
Monitor
Monitor Type
None.
Graphics Controller
Graphics Processor
Matrox G200eH
Video Memory
16 MB
Networking
Type
Integrated
Interface (Bus) Type
PCI Express x2
Ethernet Ports
2 x Gigabit Ethernet
Ethernet Controller
HP 330i
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
IPMI 2.0, SMASH CLP
Remote Management Controller
Integrated Lights-Out 4
Features
Wake on LAN (WoL), PXE support
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Expansion / Connectivity
Bays
1 (total) / 1 (free) x external 5.25" ¦ 8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots
8 (total) / 8 (free) x DIMM 288-pin ¦ 1 (total) / 1 (free) x CPU ¦ 2 (total) / 2 (free) x PCIe 3.0 x8 - half-length, full-height ¦ 2 (total) / 2 (free) x PCIe 3.0 x4 - half-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - three-quarter-length, full-height ¦ 1 (total) / 1 (free) x microSD Card (internal)
Interfaces
1 x VGA (1 rear) ¦ 2 x LAN (Gigabit Ethernet) ¦ 1 x HPE iLO ¦ 5 x USB 3.0 (2 front, 2 rear, 1 internal) ¦ 3 x USB 2.0 (2 rear, 1 internal)
Miscellaneous
Features
Administrator password, power-on password, serial port I/O control, Setup Password, UEFI BIOS
Compliant Standards
ACPI 2.0b, FCC Class B certified, CISPR 24, ICES-003, EN 61000-3-3, CISPR 22, FCC CFR47 Part 15, IEC 60950-1, EN 60950-1, GB 9254, CNS 13438
Pricing Type
CTO
Power
Device Type
Power supply
Voltage Required
AC 120/230 V (50/60 Hz)
Operating System / Software
OS Certified
SUSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, Canonical Ubuntu
Manufacturer Warranty
Service & Support
Limited warranty - parts - 3 years ¦ Limited warranty - parts and labour - 1 year - on-site
Dimensions & Weight
Width
19.5 cm
Depth
48.05 cm
Height
44 cm
Weight
12.5 kg
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90%
