General
Type
Server
Product Form Factor
Tower - 5U
Embedded Security
Trusted Platform Module (TPM 1.2) Security Chip
Server Scalability
2-way
Internal Bays Qty
4
Front Accessible Bays Qty
1
Localisation
Region: Worldwide
Processor / Chipset
CPU
No CPU
Max CPU Qty
2
CPU Upgradability
Upgradable
Chipset Type
Intel C612
RAM
Installed Size
0 GB / 256 GB (max)
Technology
DDR4 SDRAM - Advanced ECC
Form Factor
DIMM 288-pin
Slots
16 (Total) / 16 (empty)
Features
Online Spare Memory, quad channel memory architecture, HP SmartMemory
RAM Supported
PC4-17000 - 256 GB Load-Reduced ¦ PC4-17000 - 256 GB registered
Storage Controller
Type
1 x RAID - integrated
Controller Interface Type
SATA 6Gb/s
Storage Controller Name
HP Dynamic Smart Array B140i
Channel Qty
10
RAID Level
RAID 0, RAID 1, RAID 5, RAID 10
Optical Storage
Type
No optical drive
Monitor
Monitor Type
None.
Graphics Controller
Type
Plug-in card
Networking
Type
Integrated
Interface (Bus) Type
PCI Express x2
Ethernet Ports
2 x Gigabit Ethernet
Ethernet Controller
HP 331i
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
IPMI 2.0, SMASH CLP
Remote Management Controller
Integrated Lights-Out 4
Features
Wake on LAN (WoL), PXE support
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Expansion / Connectivity
Bays
1 (total) / 1 (free) x external 5.25" ¦ 4 (total) / 4 (free) x internal 3.5" LFF
Slots
16 (total) / 16 (free) x DIMM 288-pin ¦ 2 (total) / 2 (free) x CPU ¦ 3 (total) / 3 (free) x PCIe 3.0 x8 - half-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - full-length, full-height ¦ 1 (total) / 1 (free) x microSD Card (internal) ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - full-length, full-height (2 processors must be installed) ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 - half-length, full-height (2 processors must be installed)
Interfaces
1 x VGA ¦ 2 x LAN (Gigabit Ethernet) ¦ 1 x HPE iLO ¦ 5 x USB 3.0 (2 front, 2 rear, 1 internal) ¦ 3 x USB 2.0 (2 rear, 1 internal)
Miscellaneous
Features
Administrator password, power-on password, serial port I/O control, Setup Password, UEFI BIOS
Compliant Standards
ACPI 2.0b, FCC Class A certified, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, FCC CFR47 Part 15, IEC 60950-1, EN 60950-1, WEEE, GB 9254, ASHRAE, CNS 13438
Pricing Type
CTO
Power
Device Type
Power supply
Voltage Required
AC 120/230 V (50/60 Hz)
Operating System / Software
OS Certified
SUSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, Oracle Solaris, Canonical Ubuntu
Manufacturer Warranty
Service & Support
Limited warranty - parts - 3 years - response time: next business day ¦ Limited warranty - parts and labour - 1 year - on-site - response time: next business day
Dimensions & Weight
Width
20 cm
Depth
62 cm
Height
43.26 cm
Weight
16.9 kg
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% (non-condensing)
