General
Type
PC barebone
Product Form Factor
Mini PC
Processor / Chipset
CPU
Intel Core i7 (11th Gen) 11700B
Clock Speed
3.2 GHz
Max Turbo Speed
4.8 GHz
Number of Cores
8-core
CPU Qty
1
Max CPU Qty
1
Processor Main Features
Intel Virtualization Technology, Intel AES New Instructions, Intel Platform Trust Technology (PTT)
Chipset Type
Intel WM590
Cache Memory
Installed Size
24 MB
Cache Per Processor
24 MB
RAM
Installed Size
0 GB / 64 GB (max)
Technology
DDR4 SDRAM
Form Factor
SO-DIMM 260-pin
Slots
2 (Total) / 2 (empty)
Storage Controller
Type
1 x SATA/NVMe
Controller Interface Type
SATA 6Gb/s / PCIe 4.0 x4 (NVMe)
RAID Level
RAID 0, RAID 1
Optical Storage
Type
No optical drive
Card Reader
Type
Card reader
Supported Flash Memory Cards
SDXC UHS-II Memory Card
Monitor
Monitor Type
None.
Graphics Controller
Interface Type
Thunderbolt 4 / HDMI
Graphics Processor
Intel UHD Graphics
Video Interfaces
HDMI, USB-C
Max Monitors Supported
3
Audio Output
Sound Output Mode
7.1 channel surround
Compliant Standards
High Definition Audio
Networking
Ethernet Ports
2.5 Gigabit Ethernet
Ethernet Controller
Intel I225-LM
Wireless LAN Supported
Yes
Wireless NIC
Intel Wi-Fi 6E AX 210
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, 802.11ax, Bluetooth 5.2
Compliant Standards
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, Wi-Fi CERTIFIED 6, Bluetooth 5.2
Expansion / Connectivity
Slots
1 (total) / 1 (free) x M.2 Card - 2280 (PCIe 4.0 x4 mode) ¦ 2 (total) / 2 (free) x M.2 Card - 2242/2280 (SATA/PCIe 3.0 x4 (NVMe)) ¦ 1 (total) / 1 (free) x M.2 Card - 2280/22110 (PCIe 4.0 x4 mode) ¦ 1 (total) / 1 (free) x PCIe 4.0 x16 - double-width ¦ 1 (total) / 1 (free) x PCIe 4.0 x4
Interfaces
2 x Thunderbolt 4/USB-C 3.2 Gen 2 ¦ 1 x HDMI ¦ 6 x USB 3.2 Gen 2 (6 rear) ¦ 1 x LAN (2.5Gigabit Ethernet) ¦ 1 x headphones/microphone - mini-jack ¦ 2 x USB 3.2 Gen 2 (2 in front)
Miscellaneous
Compliant Standards
ICES-003, EN55024, FCC Part 15 B, FCC Part 15 C, AS/NZS 4268, FCC Part 15 E, BSMI CNS 13438, REACH, EN 62311, EN 300.440, China RoHS, EN 300 328, EN 301 489-1, KN32, KN35, AS/NZS 2772.2, EN 301 893, CISPR 32, EN 55032, EN 301 489-3, EU RoHS, EN 301 489-17, ARPANSA, Taiwan BSMI RoHS, AS/NZS CISPR 32, VCCI 32
Power
Device Type
Power supply
Voltage Required
AC 100-240 V (50/60 Hz)
Power Provided
650 Watt
80 PLUS Certification
80 PLUS Gold
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
Dimensions & Weight
Width
12 cm
Depth
35.7 cm
Height
18.9 cm
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
35 °C
