General
Type
PC barebone
Product Form Factor
Slim Chassis
Sensors
Temperature sensor, voltage sensor
Localisation
Region: United Kingdom
Processor / Chipset
CPU
Intel Core i3 (13th Gen) i3-1315U
Max Turbo Speed
4.5 GHz (P-core) / 3.3 GHz (E-core)
Number of Cores
6-core
CPU Qty
1
Max CPU Qty
1
Processor Main Features
Intel Virtualization Technology, Intel Smart Cache, Intel AES New Instructions, Intel Virtualization Technology for Directed I/O, Intel Platform Trust Technology (PTT)
Cache Memory
Installed Size
10 MB
Cache Per Processor
10 MB
RAM
Installed Size
8 GB / 64 GB (max)
Technology
DDR4 SDRAM
Rated Memory Speed
3200 MHz
Form Factor
SO-DIMM 260-pin
Slots
2 (Total) / 0 (empty)
Features
Dual channel memory architecture
Configuration Features
2 x 4 GB
Hard Drive
Type
SSD - M.2
Capacity
1 x 512 GB
Features
NVM Express (NVMe)
Storage Controller
Type
SATA/NVMe
Controller Interface Type
SATA 6Gb/s / PCIe 4.0 x4 (NVMe)
Optical Storage
Type
No optical drive
Monitor
Monitor Type
None.
Graphics Controller
Interface Type
Thunderbolt 4 / HDMI
Graphics Processor
Intel UHD Graphics
Video Interfaces
HDMI, USB-C
Max Monitors Supported
4
Audio Output
Sound Output Mode
7.1 channel surround
Compliant Standards
High Definition Audio
Networking
Ethernet Controller
Intel I226-V
Wireless LAN Supported
Yes
Wireless NIC
Intel Wi-Fi 6E AX 211
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3
Expansion / Connectivity
Slots
1 (total) / 1 (free) x M.2 Card - 2280 (Key M) ¦ 1 (total) / 1 (free) x M.2 Card - 2242 (Key B) ¦ 1 (total) / 0 (free) x M.2 Card - 2230 (Key E)
Interfaces
2 x Thunderbolt 4/USB4/DisplayPort - Type C (2 rear) ¦ 3 x USB 3.2 Gen 2 - Type A (2 front, 1 rear) ¦ 1 x USB 2.0 - Type A (1 rear) ¦ 2 x USB 2.0 - header (2 internal) ¦ 2 x HDMI ¦ 1 x LAN (2.5Gigabit Ethernet) - RJ-45 ¦ 1 x headphones/microphone - stereo mini-jack
Miscellaneous
Included Accessories
VESA Adapter
Theft/Intrusion Protection
Security lock slot (cable lock sold separately)
Security Slot Type
Kensington security slot
Compliant Standards
ICES-003, EN55024, FCC Part 15 B, FCC Part 15 C, IEC 60950-1, EN 60950-1, AS/NZS 4268, FCC Part 15 E, BSMI CNS 13438, CISPR, REACH, E-Standby, ERP, CEL, EN 62311, EN 300.440, China RoHS, EN 300 328, GEMS, EN 301 489-1, KN32, KN35, EN 62368-1, IEC 62368-1, AS/NZS 2772.2, EN 301 893, EN 55032, EN 301 489-3, EU RoHS, UL 62368-1, EN 301 489-17, ARPANSA, Taiwan BSMI RoHS, AS/NZS CISPR 32, VCCI 32
Power
Device Type
Power adapter
Power Provided
90 Watt
Operating System / Software
OS Provided
Windows 11 Pro
Software
Intel Management Engine Firmware 16.1
Sustainability Information
ENERGY STAR Certified
Yes
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
Dimensions & Weight
Width
11.7 cm
Depth
11.2 cm
Height
3.7 cm
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
