General
Device Type
Switch - 8 ports - L3 Lite - Managed
Enclosure Type
Rack-mountable
Subtype
Gigabit Ethernet
Ports
8 x 10/100/1000 (PoE+) + 1 x 10/100/1000 (PoE+ input) + 2 x 1000Base-X
Power Over Ethernet (PoE)
PoE+
Performance
Switching fabric bandwidth: 24 Gbps ¦ Forwarding rate: 16.4 Mpps ¦ Buffer memory: 1.5 MB
Capacity
VLANs supported: 4094 ¦ Priority queues: 8
MAC Address Table Size
16K entries
Jumbo Frame Support
10KB
Routing Protocol
Static IPv4 routing, RIP, OSPFv2, OSPF, CIDR, RIP-2, VRRP, RSTP, PIM-SM, IGMP, IGMPv2, IGMPv3, MLD, MLDv2, MSTP, STP
Remote Management Protocol
SNMP 6, Telnet, SSH, CLI, ICMP, SNMP 1, SNMP 2c, SNMP 3, RMON 1, RMON 2, RMON 3, RMON 9, RSTP, TACACS+, HTTP, HTTPS, TFTP, SMTP, NTP, SLP, DHCP, SCP, SFTP
Encryption Algorithm
AES, Triple DES, CCM, CMAC, GCM, XTS, DSA, ECDSA, RSA, SHA-1, 224-bit SHA-2, 256-bit SHA-2, 384-bit SHA-2, 512-bit SHA-2, 256-bit SHA, 384-bit SHA, 512-bit SHA, DRBG, RNG, 128-bit AES, 192-bit AES, 256-bit AES, DES, MD5, SSL 2.0, SSL 3.0, TLS, TTLS, PEAP, TLS 1.0
Authentication Method
Secure Shell (SSH), TACACS+
Features
PoE Pass Through, AMF, Energy Efficient Ethernet, fanless, Active Fiber Monitoring, EPSRing, 802.1x authentication, flow control, BIST, Cable fault locator (TDR), DDM, port mirroring, UDLD, Syslog support, MIB, QoS, ToS, DiffServ support, BOOTP support, proxy ARP, DNS client, LLDP support, sFlow, VACM, BSR Mechanism, LACP support, AAA, SNTP support, GVRP, VoIP support, LLDP-MED, Voice VLAN, CPP, SLP, loop prevention, STP Root Guard, BPDU, DHCP snooping, IP source guard, dynamic ARP protection, DAI, DoS attack prevention, NAC, SCP
Compliant Standards
IEEE 802.1x, IEEE 802.3x, IEEE 802.2, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3az, IEEE 802.3u, IEEE 802.3z, IEEE 802.1ab (LLDP), IEEE 802.1p, IEEE 802.3ad (LACP), IEEE 802.1D, IEEE 802.1s, IEEE 802.1AX, IEEE 802.1w, IEEE 802.1Q, IEEE 802.1v, IEEE 802.3ac, ANSI/TIA-1057
RAM
512 MB DDR3 SDRAM
Flash Memory
128 MB
Status Indicators
Status
