General
Type
Personal computer
Product Form Factor
All-in-one - with UltraFlex IV Stand
Built-in Devices
Stereo speakers
Embedded Security
Discrete Trusted Platform Module (TPM 1.2) Security Chip
Colour
Black
Localisation
Language: English / region: United Kingdom
Processor / Chipset
CPU
Intel Core i7 (10th Gen) 10700
Clock Speed
2.9 GHz
Max Turbo Speed
4.8 GHz
Number of Cores
8-core
CPU Qty
1
Max CPU Qty
1
Chipset Type
Intel H470
Cache Memory
Installed Size
16 MB
Cache Per Processor
16 MB
RAM
Installed Size
8 GB / 64 GB (max)
Technology
DDR4 SDRAM
Effective Memory Speed
2933 MHz
Rated Memory Speed
2933 MHz
Form Factor
SO-DIMM 260-pin
Slots
2 (Total) / 1 (empty)
Features
Dual channel memory architecture
Configuration Features
1 x 8 GB
Hard Drive
Type
HDD
Capacity
1 x 1 TB
Interface Type
SATA 6Gb/s
Spindle Speed
7200 rpm
Storage Controller
Type
1 x SATA
Optical Storage
Type
DVD-Writer - SATA
Card Reader
Type
3 in 1 card reader
Monitor
Monitor Type
LED - IPS
Touchscreen
Yes (10-point multi-touch)
Diagonal Size
21.5"
Native Resolution
1920 x 1080 (Full HD)
Widescreen Display
Yes
Image Aspect Ratio
16:9
Horizontal Viewing Angle
178
Vertical Viewing Angle
178
Image Brightness
250 cd/m²
Image Contrast Ratio
1000:1
Monitor Features
Anti-glare, borderless, Advanced In-Cell Touch (AIT) technology
Graphics Controller
Graphics Processor
Intel UHD Graphics 630 Shared Video Memory (UMA)
Video Interfaces
DisplayPort
Audio Output
Compliant Standards
High Definition Audio
Speakers Included
2 x right / left channel
Camera
Camera
Yes
Resolution
1080p
Features
ThinkShutter camera privacy
Input Device
Type
Mouse, keyboard
Keyboard
Keyboard Name
Lenovo Calliope Keyboard
Interface
USB
Localization & Layout
UK
Mouse
Mouse Name
Lenovo Calliope Mouse
Interface
USB
Audio Input
Type
Dual array microphone
Networking
Ethernet Controller
Realtek RTL8111K
Wireless LAN Supported
Yes
Wireless NIC
Intel Wireless-AC 9560
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0
Features
Wake on LAN (WoL), dual stream (2x2)
Expansion / Connectivity
Bays
1 (total) / 1 (free) x internal 2.5"
Slots
2 (total) / 0 (free) x M.2 Card
Interfaces
5 x USB 3.2 Gen 1 (4 rear, 1 side) (one of them supports SmartPower On) ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x DisplayPort ¦ 1 x USB 3.2 Gen 2 (1 side) ¦ 1 x USB-C 3.2 Gen 1 (1 side) (charging) ¦ 1 x headphones/microphone (1 side)
Miscellaneous
Included Accessories
VESA mounting kit
Theft/Intrusion Protection
Security lock slot (cable lock sold separately), chassis intrusion switch
Security Slot Type
Kensington security slot
VESA Mounting Interface
100 x 100 mm
Compliant Standards
RoHS, Energy-Related Products (ErP) Lot 3, TUV Rheinland Ultra Low Noise Certification, MIL-STD-810H
Manufacturer Selling Program
TopSeller
Power
Device Type
Power adapter
Voltage Required
AC 100-240 V (50/60 Hz)
Power Provided
170 Watt
Efficiency
89%
Operating System / Software
OS Provided
Windows 10 Pro 64-bit Edition English
Environmental Standards
TCO Certified
TCO Certified Edge All-in-One PCs, TCO Certified All-in-One PCs 8
EPEAT Compliant
EPEAT Silver
ENERGY STAR Certified
Yes
ENERGY STAR Version
8.0
Manufacturer Warranty
Service & Support
Limited warranty - 3 years - on-site
Dimensions & Weight
Dimensions & Weight Details
49.017 cm - 28.817 cm - 19.704 cm - 7.65 kg - with stand (lowest position in flat mode) ¦ 49.017 cm - 23.275 cm - 43.928 cm - 7.65 kg - with stand (highest position in vertical mode)
Width
49.017 cm
Depth
23.275 cm
Height
44.073 cm
Weight
7.65 kg
Environmental Parameters
Min Operating Temperature
5 °C
Max Operating Temperature
35 °C
Humidity Range Operating
20 - 80%
