General
Platform Technology
Intel vPro Enterprise
Type
Workstation
Product Form Factor
Tower
Built-in Devices
Speaker
Embedded Security
Discrete Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Language: English / region: United Kingdom
Processor / Chipset
CPU
Intel Xeon W5-3433
Clock Speed
2 GHz
Max Turbo Speed
4.2 GHz
Number of Cores
16-core
CPU Qty
1
Max CPU Qty
1
CPU Socket
FCLGA4677 Socket
Chipset Type
Intel W790
Cache Memory
Installed Size
45 MB
Cache Per Processor
45 MB
RAM
Installed Size
32 GB (installed) / 1 TB (max)
Technology
DDR5 SDRAM - ECC
Effective Memory Speed
4800 MHz
Rated Memory Speed
4800 MHz
Form Factor
DIMM 288-pin
Slots
8 (Total) / 6 (empty)
Features
Registered
Configuration Features
2 x 16 GB
Hard Drive
Type
SSD - M.2 2280
Capacity
1 x 1 TB
Interface Type
PCI Express 4.0 x4
Features
TCG Opal Encryption, NVM Express (NVMe), Performance
Storage Controller
Type
1 x RAID
Controller Interface Type
SATA 6Gb/s
RAID Level
RAID 0, RAID 1, RAID 5
Storage Controller (2nd)
Type
1 x NVMe
Controller Interface Type
PCI Express
Optical Storage
Type
No optical drive
Card Reader
Type
15 in 1 card reader
Monitor
Monitor Type
None.
Audio Output
Compliant Standards
High Definition Audio
Input Device
Type
Mouse, keyboard
Keyboard
Keyboard Name
Lenovo Traditional Keyboard
Interface
USB
Localization & Layout
UK
Mouse
Mouse Name
Lenovo Calliope Mouse
Interface
USB
Networking
Ethernet Ports
1 x 10 Gigabit Ethernet, 1 x Gigabit Ethernet
Ethernet Controller
Marvell AQtion AQC-113C, Intel I219-LM
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet
Features
Wake on LAN (WoL), Intel Active Management Technology (AMT) 16
Expansion / Connectivity
Bays
2 (total) / 2 (free) x internal 3.5"
Slots
3 (total) / 2 (free) x PCIe 5.0 x16 ¦ 1 (total) / 1 (free) x PCIe 4.0 x16 ¦ 1 (total) / 1 (free) x PCIe 4.0 x8 ¦ 1 (total) / 1 (free) x PCIe 5.0 x4 ¦ 1 (total) / 1 (free) x PCIe 4.0 x4 ¦ 3 (total) / 2 (free) x M.2 Card
Interfaces
1 x USB-C 3.2 Gen 2x2 (1 rear) ¦ 2 x USB 2.0 (2 rear) ¦ 3 x USB 3.2 Gen 2 (3 rear) ¦ 1 x LAN (Gigabit Ethernet) (1 rear) ¦ 1 x LAN (10Gigabit Ethernet) (1 rear) ¦ 1 x audio line-in (1 rear) ¦ 1 x audio line-out (1 rear) ¦ 1 x headphones/microphone (1 front) ¦ 2 x USB-C 3.2 Gen 2 (2 front) (data only) ¦ 1 x USB 3.2 Gen 2 (1 front) (Always On) ¦ 1 x USB 3.2 Gen 2 (1 front)
Miscellaneous
Included Accessories
Lock kit (common key)
Theft/Intrusion Protection
Security lock slot (cable lock sold separately), chassis intrusion switch
Security Slot Type
Kensington security slot
Compliant Standards
RoHS, FIPS 140-2, TCG Certified, TCO Certified 9.0
Manufacturer Selling Program
Lenovo TopSeller
Power
Device Type
Power supply
Voltage Required
AC 100-240 V (50/60 Hz)
Power Provided
1400 Watt
80 PLUS Certification
80 PLUS Platinum
Efficiency
92%
Operating System / Software
OS Provided
Windows 11 Pro for Workstations English
Sustainability Information
EPEAT Compliant
EPEAT Gold
ENERGY STAR Certified
Yes
ENERGY STAR Version
8.0
Carbon Footprint
2938 kg carbon emissions
Total CF/unit Standard Deviation (kg CO2e)
1080
PAIA Version
1.3.2
Manufacturer Warranty
Service & Support
Limited warranty - 3 years - on-site
Dimensions & Weight
Width
17.5 cm
Depth
50.8 cm
Height
43.44 cm
Weight
24.5 kg
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
20 - 80%
