Lenovo ThinkSystem PM1645a Mainstream - SSD - 800 GB - hot-swap - 2.5" - SAS 12Gb/s - for ThinkAgile MX3330-F Appliance, MX3330-H Appliance, MX3331-F Certified Node
Checking delivery…
Payment options available at checkout
Main features
Lenovo ThinkSystem PM1645a Mainstream
SSD
800 GB
hot-swap
2.5"
SAS 12Gb/s
for ThinkAgile MX3330-F Appliance; MX3330-H Appliance; MX3331-F Certified Node
Overview
The ThinkSystem PM1645a Mainstream SAS 12Gb solid-state drives (SSDs) are high-performance SSDs suitable for a wide range of applications of running on ThinkSystem servers. Unlike SATA drives, the 12 Gb/s SAS interface on these drives supports full duplex data transfer for higher performance and enterprise-level error recovery for better availability.
Product Description
Lenovo ThinkSystem PM1645a Mainstream - SSD - 800 GB - SAS 12Gb/s
Type
Solid state drive - hot-swap
Capacity
800 GB
Form Factor
2.5"
Interface
SAS 12Gb/s
Data Transfer Rate
1.2 GBps
Features
End-to-end data protection, power loss data protection, Tagged Command Queuing (TCQ), S.M.A.R.T.
Dimensions (WxDxH)
70 mm x 100 mm x 15 mm
Weight
140 g
Manufacturer Warranty
1-year warranty
Designed For
ThinkAgile HX1330 Appliance; HX1331 Certified Node; HX2330 Appliance; HX2331 Certified Node; HX33XX Appliance; HX33XX Certified Node; HX5530 Appliance; HX5531 Certified Node; HX7530 Appliance; HX7531 Certified Node; MX3330-F Appliance; MX3330-H Appliance; MX3331-F Certified Node; MX3331-H Certified Node; MX3530-H Hybrid Appliance; MX3531-H Hybrid Certified Node; ThinkAgile VX Certified Node 7Y94, 7Z12; ThinkAgile VX3331; VX33XX Appliance; VX3530-G Appliance; VX3575-G Integrated System; VX3720 Appliance; VX5575 Integrated System; VX7575 Integrated System; VX75XX Appliance; VX75XX Certified Node; VX7820 Appliance; ThinkSystem SR630 V2; SR645; SR650 V2; SR670 V2; SR850 V2; SR860 V2; ST650 V2
General
Device Type
Solid state drive - hot-swap
Capacity
800 GB
Form Factor
2.5"
Interface
SAS 12Gb/s
Features
End-to-end data protection, power loss data protection, Tagged Command Queuing (TCQ), S.M.A.R.T.
Width
70 mm
Depth
100 mm
Height
15 mm
Weight
140 g
Performance
Drive Writes Per Day (DWPD)
3
SSD Endurance
4380 TB
Drive Transfer Rate
1.2 GBps (external)
Internal Data Rate
1000 MBps (read) / 1000 MBps (write)
4KB Random Read
230000 IOPS
4KB Random Write
90000 IOPS
Average Latency
45 µs
Reliability
MTBF
2,000,000 hours
Non-Recoverable Errors
1 per 10^17
Expansion & Connectivity
Interfaces
1 x SAS 12 Gb/s
Compatible Bay
2.5"
Power
Power Consumption
9 Watt (read) ¦ 9 Watt (write)
Miscellaneous
Included Accessories
Hot-plug tray
Compliant Standards
UL, TUV, FCC, IC, CB, C-Tick, BSMI, KCC, VCCI, RoHS
Dimensions & Weight (Shipping)
Shipping Width
13.3 cm
Shipping Depth
17.4 cm
Shipping Height
6.3 cm
Manufacturer Warranty
Service & Support
Limited warranty - replacement - 1 year
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
70 °C
Humidity Range Operating
5 - 95% (non-condensing)
Shock Tolerance (non-operating)
1500 g @ 0.5 ms
Vibration Tolerance (non-operating)
20 g @ 10-2000 Hz
Compatibility Information
Designed For
Lenovo ThinkAgile HX1330 Appliance 7Z85 (2.5") ¦ Lenovo ThinkAgile HX1331 Certified Node 7D52 (2.5") ¦ Lenovo ThinkAgile HX2330 Appliance 7Z85 (2.5") ¦ Lenovo ThinkAgile HX2331 Certified Node 7D52 (2.5") ¦ Lenovo ThinkAgile HX3330 Appliance 7Z85 (2.5") ¦ Lenovo ThinkAgile HX3331 Certified Node 7D52 (2.5") ¦ Lenovo ThinkAgile HX3375 Appliance 7D5U (2.5") ¦ Lenovo ThinkAgile HX3376 Certified Node 7D5U (2.5") ¦ Lenovo ThinkAgile HX5530 Appliance 7Z82 (2.5") ¦ Lenovo ThinkAgile HX5531 Certified Node 7Z84 (2.5") ¦ Lenovo ThinkAgile HX7530 Appliance 7Z82 (2.5") ¦ Lenovo ThinkAgile HX7531 Certified Node 7Z84 (2.5") ¦ Lenovo ThinkAgile MX3330-F Appliance 7D19 (2.5") ¦ Lenovo ThinkAgile MX3330-H Appliance 7D19 (2.5") ¦ Lenovo ThinkAgile MX3331-F Certified Node 7D67 (2.5") ¦ Lenovo ThinkAgile MX3331-H Certified Node 7D67 (2.5") ¦ Lenovo ThinkAgile MX3530-H Hybrid Appliance 7D6B (2.5") ¦ Lenovo ThinkAgile MX3531-H Hybrid Certified Node 7D66 (2.5") ¦ Lenovo ThinkAgile VX Certified Node 7Y94 (2.5"), 7Z12 (2.5") ¦ Lenovo ThinkAgile VX3320 Appliance 7Y93 (2.5") ¦ Lenovo ThinkAgile VX3330 Appliance 7Z62 (2.5") ¦ Lenovo ThinkAgile VX3331 7Z62 (2.5") ¦ Lenovo ThinkAgile VX3530-G Appliance 7Z63 (2.5") ¦ Lenovo ThinkAgile VX3575-G Integrated System 7D43 (2.5") ¦ Lenovo ThinkAgile VX5575 Integrated System 7D43 (2.5") ¦ Lenovo ThinkAgile VX7520 Appliance 7Y94 (2.5") ¦ Lenovo ThinkAgile VX7530 Appliance 7Z63 (2.5") ¦ Lenovo ThinkAgile VX7531 Certified Node 7Z63 (2.5") ¦ Lenovo ThinkAgile VX7575 Integrated System 7D43 (2.5") ¦ Lenovo ThinkAgile VX7576 Certified Node 7D43 (2.5") ¦ Lenovo ThinkAgile VX7820 Appliance 7Z13 (2.5") ¦ Lenovo ThinkSystem SR630 V2 7Z71 (2.5") ¦ Lenovo ThinkSystem SR650 V2 7D15 (2.5"), 7Z73 (2.5") ¦ Lenovo ThinkSystem SR670 V2 7Z23 (2.5") ¦ Lenovo ThinkSystem SR850 V2 7D32 (2.5") ¦ Lenovo ThinkSystem SR860 V2 7Z60 (2.5") ¦ Lenovo ThinkSystem ST650 V2 7Z74 (2.5"), 7Z75 (2.5")
