GIGABYTE

MB AMD AM4 A520 A520M H DDR4 M-ITX

Name: MB AMD AM4 A520 A520M H DDR4 M-ITX
Brand: GIGABYTE
SKU: 1TCPTMOT-004151
Price: 83.51 GBP
Availability: OutOfStock

SKU

1TCPTMOT-004151

Manufacture#: A520I AC

£69.59

£83.51 inc VAT

Checking delivery…

Product details

1.0
motherboard
mini ITX
Socket AM4

View full product specification

Notify me when this product is in stock

Payment options available at checkout

Compare product

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Overview

Main features

Gigabyte A520I AC
1.0
motherboard
mini ITX
Socket AM4
AMD A520 Chipset
USB 3.2 Gen 1
Gigabit LAN, Wi-Fi, Bluetooth
onboard graphics (CPU required)
HD Audio (8-channel)

Overview

Gigabyte A520I AC - 1.0 - motherboard - mini ITX - Socket AM4 - AMD A520

Specification

Product Description Gigabyte A520I AC - 1.0 - motherboard - mini ITX - Socket AM4 - AMD A520

Product Type Motherboard - mini ITX

Chipset Type AMD A520

Processor Socket 1 x Socket AM4

Compatible Processors Ryzen (supports 3rd Generation Ryzen / 3rd Generation Ryzen with Radeon Graphics)

Max RAM Size 64 GB

RAM Supported 2 DIMM slots - DDR4, non-ECC, ECC, unbuffered

Storage Ports 4 x SATA-600 (RAID), 1 x M.2

USB / FireWire Ports 4 x USB 3.2 Gen 1 + 2 x USB 2.0 + (2 x USB 3.2 Gen 1 + 2 x USB 2.0 via headers)

Audio HD Audio (8-channel)

LAN Gigabit Ethernet, 802.11a/b/g/n/ac, Bluetooth 4.2

General

Product Type Motherboard - mini ITX

Chipset Type AMD A520

Processor Socket Socket AM4

Max Processors Qty 1

Compatible Processors Ryzen (supports 3rd Generation Ryzen / 3rd Generation Ryzen with Radeon Graphics)

Supported RAM

Max Size 64 GB

Technology DDR4

Bus Clock 2400 MHz, 2133 MHz, 2667 MHz, 2933 MHz, 3200 MHz, 3333 MHz (O.C.), 3600 MHz (O.C.), 4000 MHz (O.C.), 4400 MHz (O.C.), 4600 MHz (O.C.), 4866 MHz (O.C.), 5100 MHz (O.C.), 5200 MHz (O.C.), 5300 MHz (O.C.)

Supported RAM Integrity Check Non-ECC, ECC

Registered or Buffered Unbuffered

Features Dual channel memory architecture

Audio

Type HD Audio (8-channel)

Audio Codec Realtek ALC887

Compliant Standards High Definition Audio

LAN

Network Interfaces Gigabit Ethernet, 802.11a/b/g/n/ac, Bluetooth 4.2

Expansion / Connectivity

Expansion Slots 1 x CPU ¦ 2 x DIMM 288-pin ¦ 1 x PCIe 3.0 x16

Storage Interfaces SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 ¦ SATA-600 / PCIe 3.0 -connectors: 1 x M.2

Interfaces 1 x LAN (Gigabit Ethernet) ¦ 1 x audio line-in - mini-jack ¦ 1 x audio line-out - mini-jack ¦ 1 x microphone - mini-jack ¦ 1 x DisplayPort ¦ 2 x HDMI ¦ 4 x USB 3.2 Gen 1 ¦ 2 x USB 2.0

Internal Interfaces 2 x USB 2.0 - header ¦ 2 x USB 3.2 Gen 1 - header ¦ 1 x audio - header ¦ 1 x serial - header ¦ 1 x speaker - header

Power Connectors 24-pin main power connector, 8-pin ATX12V connector

Features

BIOS Type AMI

BIOS Features UEFI BIOS, SMBIOS 2.7 support, DMI 2.7 support, ACPI 5.0 support, WfM 2.0 support

Hardware Monitoring CPU core temperature, chassis temperature, CPU fan tachometer, chassis fan tachometer, system voltage, CPU overheating protection, CPU core voltage

Hardware Features Q-Flash Plus, Game Boost, On/Off Charge, RGB FUSION 2.0, Q-Flash, 6 Phase Power Design, Ultra Durable, Solid Pin Power Connectors, Dr.MOS MOSFET, GIGABYTE Smart Fan 5, GIGABYTE Double Locking Bracket, Anti-Sulfur Design

Miscellaneous

Software Included Norton Internet Security, @BIOS, EasyTune, GIGABYTE Fast Boot, GIGABYTE Smart Backup, GIGABYTE App Center, Xpress Install, Realtek Gaming LAN Bandwidth Control

Width 17 cm

Depth 17 cm
