Microchip PD-9001GI/DC - PoE injector - 30 Watt
Manufacture#: PD-9001GI/DC
Order by 15:00 and receive your order on Monday 21 Jul
Product details
PoE injector (DIN rail mountable)
DC 20
60 V
30 Watt
Payment options available at checkout
Main features
Microchip PD-9001GI/DC
PoE injector (DIN rail mountable)
DC 20
60 V
30 Watt
output connectors: 1
Overview
Microchip's PD-9001GI is a single port, high-power solution for remote powering of current and emerging of current and emerging high-power applications.
The PD-9001GI Family is designed for a range of applications including 802.11n Access Points, pan-tilt zoom (PTZ) cameras and other IP terminals. It complies with IEEE 802.3at PoE standard and is backward compatible to IEEE802.3af.
It can power both 10/100Base-T network devises and 1000Base-T devices. The PD-9001GI is designed for industrial applications and outdoor applications from temperature point of view.
IEEE 802.3at compliant - 30 W output
Dual DC input - 20-60VDC range
Industrial rated IP30
Extended temp range -40 °C to +75 °C
Plug-and-Play installation
Supports 10/100/1000 Mbps
Product Description
Microchip PD-9001GI/DC - PoE injector - 30 Watt
Device Type
PoE injector - DIN rail mountable
Weight
315 g
Input Voltage
DC 20 - 60 V
Output Voltage
50 V
Power Capacity
30 Watt
Output connectors
1 x RJ-45
Included Accessories
Mounting kit
Dimensions (WxDxH)
3.1 cm x 7.8 cm x 11.1 cm
Manufacturer Warranty
1-year warranty
General
Device Type
PoE injector - DIN rail mountable
Power Device
Input Voltage
DC 20 - 60 V
Power Output Connectors Details
1 x RJ-45
Output Voltage
50 V
Power Capacity
30 Watt
Expansion / Connectivity
Interfaces
1 x Gigabit LAN - RJ-45
Miscellaneous
Included Accessories
Mounting kit
MTBF
170,000 hours
Features
Wall mountable, LED indicators
Compliant Standards
IEEE 802.3af, IEEE 802.3at, EN55024, EN55022 Class A, RoHS, WEEE, IEC 60068-2-27, IEC 60068-2-32, IEC 60068-2-6, UL 508, REACH, IP30
Manufacturer Warranty
Service & Support
Limited warranty - 1 year
Environmental Parameters
Min Operating Temperature
-40 °C
Max Operating Temperature
75 °C
Dimensions & Weight
Width
3.1 cm
Depth
7.8 cm
Height
11.1 cm
Weight
315 g
