General
Product Type
LED-backlit LCD flat panel display
Energy Label QR Code URL
Https://eprel.ec.europa.eu/qr/1749415
Energy Class
Class G
Energy Class (HDR)
Class G
Power Consumption Operational
140 Watt
Power Consumption SDR (On mode)
144 kWh/1000h
Power Consumption HDR (On mode)
145 kWh/1000h
Diagonal Class
65"
Diagonal Size
64.5"
Commercial Use
Yes - digital signage
Combined With
Built-in SoC media player
Series
ME Series
Platform
Android
Operating System
Android OS 13
HDR Capable
Yes
HDR Format
HDR10, HLG10
HDR Technology
Perceptual Quantizer (PQ)
TV Tuner
No tuner
TV Tuner Presence
No
Video Interface
HDMI, USB-C
HDMI Ports Qty
3 ports
PC Interface
USB-C
Modes
Portrait mode, landscape mode
Design
Metal backcover
Dimensions
Without stand
Width
146.33 cm
Depth
6.8 cm
Height
83.82 cm
Weight
23.9 kg
Enclosure Colour
Pantone (Process Black M)
Display
LCD Display Technology
IPS
Colour Support
1073000000 colours
Resolution
3840 x 2160
Display Format
4K UHD (2160p)
Image Aspect Ratio
16:9
Frame Rate & Enhancement Technology
60 Hz Refresh Rate
LCD Backlight Technology
Direct-lit LED
Coating
25% haze
Image Contrast Ratio
1200:1
Brightness
450 cd/m²
Viewing Angle
178 degrees
Viewing Angle (Vertical)
178 degrees
Response Time
8 ms
Operation Hours / Days
18 / 7
Features
Automatic alarm e-mails, Crestron Connected Compatible, 18/7 operation time, NaViSet Administrator 2, AMX NetLinx support, ASCII Control Commands, removable logo, 8-bit support, scheduled timer, Frame Rate Control (FRC), ARC Support through HDMI, disable HW buttons, disable IR functionality
Stands & Mounts
Flat Panel Mount Interface
600 x 400 mm
VESA Compatibility
Yes
Video Features
Supported Computer Resolutions
1366 x 768, 1920 x 1200 (WUXGA), 1024 x 768 (XGA), 640 x 480 (VGA), 800 x 600 (SVGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 720 x 480, 1280 x 720, 1360 x 768, 1920 x 1080, 1440 x 900, 1280 x 800, 1400 x 1050, 720 x 576, 3840 x 2160, 4096 x 2160, 1920 x 2160, 1680 x 1050
Media Player
Supported Video Formats
MPEG-1, MPEG-2, MPEG-4, MKV, H.264, HEVC, H.265
Supported Audio Formats
MP3
USB Port
Yes
Configuration
4 GB - 32 GB
Remote Control
Type
Remote control
Battery Form Factor
AAA type
Battery Included
Yes
Audio System
Speaker System
2 speakers
Output Power / Total
20 Watt
Speakers
2 x main channel speaker
Network & Internet Multimedia
Connectivity
LAN
LAN Protocol
Fast Ethernet
Connections
Connector Type
USB-C 3.0 ¦ 3 x HDMI input ¦ Remote control ¦ Audio output ¦ RS-232 input ¦ LAN ¦ 3 x USB 2.0 downstream
Miscellaneous
Included Accessories
Remote control, batteries
Cables Included
HDMI cable
Compliant Standards
FCC Class B certified, VCCI, BSMI, VESA FDMI, PSB, RoHS, KCC, KC, EMC Class B, RCM, IP5X, UL 94-5VB, ISO 9241-307 Class 1, HDCP 2.2, HDCP 1.3, CTS-compliant
Sustainability Information
ENERGY STAR Certified
Yes
ENERGY STAR Version
8.0
Power
Power Device
Power supply
Input Voltage
AC 100-240 V (50/60 Hz)
Power Consumption Stand by
0.5 Watt
Manufacturer Warranty
Service & Support
Limited warranty - 3 years ¦ Limited warranty - backlight - 3 years
Dimensions & Weight (Shipping)
Width (Shipping)
162.8 cm
Depth (Shipping)
18.5 cm
Height (Shipping)
94.2 cm
Weight (Shipping)
34.5 kg
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
20 - 80%
