Overview
This accessory module is built to insert into any one of the 4 high-speed module bays found on either the ProSAFE GSM7428S or ProSAFE GSM7352S. Once inserted, the high-speed module bay can then be utilized with standard 10GBASE-X XFP modules for fiber connectivity at 10Gbps speeds. Specifically, this adapter module accommodates the ProSAFE AXM75110GBASE-SR “Short Reach” or ProSAFE AXM752 10GBASE-LR “Long Reach” XFP optics modules. The AX741 is hot-swappable at any time into the switch and provides hot-swappable installation or removal of standard 10GBASE-X XFP optics modules.¦ProSAFE AX742 24Gbps Stacking Kit¦This accessory kit is utilized to connect two switches together in order to configure them into an operational stack of switches. The kit supplies 2 AX742 Stacking modules and a single high-capacity stacking cable. A minimum of a single kit is required to create a stack between two switches. A group of up to 8 switches can be interconnected to form a single stack by cascading the connections between switches. It is recommended that a final connection be established between the first and the last switch to create a loop topology. This provides two 24Gbps connections per switch within the stack. Once connected the stack operates as a 48Gbps resilient, self-healing, bi-directional ring.
