NITRO+ AMD RX 6950 XT GAMING OC 16GB GDDR6 HDMI / TRIPLE DP
Manufacture#: 11317-02-20G
Checking delivery…
Product details
- Graphics card
- Radeon RX 6950 XT
- 16 GB GDDR6
- PCIe 4.0
Payment options available at checkout
Main features
- Sapphire NITRO+ Radeon RX 6950 XT
- Graphics card
- Radeon RX 6950 XT
- 16 GB GDDR6
- PCIe 4.0
- HDMI, 3 x DisplayPort
Overview
Sapphire NITRO+ Radeon RX 6950 XT - graphics card - Radeon RX 6950 XT - 16 GB
Product Description
Sapphire NITRO+ Radeon RX 6950 XT - graphics card - Radeon RX 6950 XT - 16 GB
Device Type
Graphics card
Bus Type
PCI Express 4.0
Graphics Engine
AMD Radeon RX 6950 XT
Memory
16 GB GDDR6
Memory Speed
18 Gbps
Boost Clock
2324 MHz
Stream Processors
5120
Memory Interface
256-bit
Max Resolution
7680 x 4320
Max Monitors Supported
4
Interfaces Details
HDMI ¦ 3 x DisplayPort
API Supported
DirectX 12 Ultimate
Dimensions (WxDxH)
5.84 cm x 32 cm x 13.485 cm
General
Device Type
Graphics card
Bus Type
PCI Express 4.0
Graphics Engine
AMD Radeon RX 6950 XT
Boost Clock
2324 MHz
Stream Processors
5120
Process Technology
7 nm
VR Ready
Yes
Max Resolution
7680 x 4320
Max Monitors Supported
4
Interfaces Details
HDMI ¦ 3 x DisplayPort
API Supported
DirectX 12 Ultimate
Features
Dual Bios, UEFI BIOS, Sapphire Tri-X Cooling Technology, Intelligent Fan Control (IFC), FreeSync Technology, NITRO Glow RGB LED, fuse protection, 2.7-slot Fan Cooler, Triple Fan Design, Precision Fan Control, Radeon Image Sharpening, Radeon Anti-Lag, AMD FidelityFx, TriXX Boost, Fan Quick Connect, TriXX Supported, ARGB Lighting, RDNA 2 Architecture, AMD Infinity Cache, DirectX Raytracing (DXR), Video Streaming up to 8K, Hybrid Fan Blade, V-shape fin design, WAVE fin design, Dual ball Bearing Fans, AMD FidelityFX Super Resolution (FSR), Fan Check, metal backplate
Memory
Size
16 GB
Technology
GDDR6 SDRAM
Memory Speed
18 Gbps
Bus Width
256-bit
System Requirements
OS Required
Linux, Microsoft Windows 7 / 8.1 / 10 (64 bit)
Min RAM Size
8 GB
Required Power Supply
850 W
Additional Requirements
6 pin PCI Express power connector, 2 x 8 pin PCI Express power connector
Miscellaneous
Power Consumption Operational
391 Watt
Software Included
Sapphire TriXX
Compliant Standards
DisplayPort 1.4, DSC
Width
5.84 cm
Depth
32 cm
Height
13.485 cm
