General
Device Type
NAS server
Host Connectivity
2.5 Gigabit Ethernet
Total Storage Capacity
24 TB
Installed Devices / Modules Qty
6 (installed) / 6 (max)
Width
26.43 cm
Depth
28.08 cm
Height
18.82 cm
Weight
)
Built-in Devices
Led panel
Processor / Memory
Processors Installed
1 x AMD Ryzen Embedded V1500B 2.2 GHz
Number of Cores
Quad-Core
Max Supported Qty
1
RAM
8 GB (installed) / 64 GB (supported) - DDR4
Flash Memory Installed
5 GB
Storage Controller
Type
RAID
Interface Type
SATA 6Gb/s
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, JBOD
Networking
Data Link Protocol
100Mb LAN, 1GbE, 2.5GbE
Remote Management Protocol
Telnet, HTTP, HTTPS, SSH
Network Services Compatibility
Microsoft Active Directory (AD), Microsoft CIFS, FTP, Server Message Block (SMB), Apple File Protocol (AFP)
Features
NAT support, hardware encryption, LDAP support, wake on LAN (WOL), Spanning Tree Protocol (STP) support, Jumbo Frames support, DHCP server, FTP server, reset button, DHCP client, static routing, VPN Server, AES encryption, DLNA support, Chromecast support, file station, port trunking, USB One Touch Copy, IFTTT agent, hybrid backup sync, Qfiling, Qsirch, Qcontactz, Qfinder Pro, Q'center (NAS CMS), VJBOD Cloud, myQNAPcloud, Qsync, QuMagie, Qmiix agent
Encryption Algorithm
AES-NI
Expansion / Connectivity
Expansion Bays
6 (total) / 0 (free) x hot-swap - 2.5" / 3.5"
Expansion Slots
2 (total) / 1 (free) x SO-DIMM 260-pin ¦ 2 (total) / 2 (free) x M.2 2280 ¦ 2 (total) / 2 (free) x PCI Express 3.0 x4
Interfaces
2 x 2.5 Gigabit Ethernet - RJ-45 ¦ 3 x USB 3.2 Gen 2 - Type A ¦ 1 x USB 3.2 Gen 1 - Type C
