QNAP

QNAP TS-h1277XU-RP - NAS server - 12 bays - rack-mountable - SATA 6Gb/s - RAID 0, 1, 5, 6, 10, 50, JBOD, 5 hot spare, 6 hot spare, 60, 10 hot spare, RAID TP - RAM 32 GB - Gigabit Ethernet / 10 Gigabit Ethernet / 10Gbps SFP+ - iSCSI support - 2U

Name: QNAP TS-h1277XU-RP - NAS server - 12 bays - rack-mountable - SATA 6Gb/s - RAID 0, 1, 5, 6, 10, 50, JBOD, 5 hot spare, 6 hot spare, 60, 10 hot spare, RAID TP - RAM 32 GB - Gigabit Ethernet / 10 Gigabit Ethernet / 10Gbps SFP+ - iSCSI support - 2U
Brand: QNAP
SKU: 1TNETNHS-028919
Price: 4185.98 GBP
Availability: OutOfStock

SKU

1TNETNHS-028919

Manufacture#: TS-H1277XU-RP-3700X-32G

£3488.32

£4185.98 inc VAT

Checking delivery…

Product details

NAS server
12 bays
rack-mountable
SATA 6Gb/s

View full product specification

Notify me when this product is in stock

Payment options available at checkout

Compare product

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Overview

Main features

QNAP TS-h1277XU-RP
NAS server
12 bays
rack-mountable
SATA 6Gb/s
RAID 0, 1, 5, 6, 10, 50, JBOD, 5 hot spare, 6 hot spare, 60, 10 hot spare, RAID TP
RAM 32 GB
Gigabit Ethernet / 10 Gigabit Ethernet / 10Gbps SFP+
iSCSI support
2U

Overview

The TS-h1277XU-RP supports near-limitless snapshots, block-level inline data deduplication, and inline data compression. The TS-h1277XU-RP helps your business achieve reliable service-level agreement performance, whether in mission-critical file server, virtualization server, VDI, collaborative video editing, or efficient file backup and recovery applications.

Specification

Product Description QNAP TS-h1277XU-RP - NAS server

Device Type NAS server

Host Connectivity Gigabit Ethernet / 10 Gigabit Ethernet / 10Gbps SFP+

Enclosure Type Rack-mountable - 2U

Installed Devices / Modules Qty 0 (installed) / 12 (max)

Dimensions (WxDxH) 48.2 cm x 56.2 cm x 8.83 cm

Weight 13.73 kg ()

Processor 1 x AMD Ryzen 7 3700X 3.6 GHz (8-core)

Storage Controller RAID SATA 6Gb/s RAID 0, 1, 5, 6, 10, 50, JBOD, 5 hot spare, 6 hot spare, 60, 10 hot spare, RAID TP

Networking 1GbE, 10GbE, 10 GigE optical

RAM 32 GB

Power AC 120/230 V

Power Redundancy Yes

Storage Operating System QNAP QTS hero

General

Device Type NAS server

Host Connectivity Gigabit Ethernet / 10 Gigabit Ethernet / 10Gbps SFP+

Enclosure Type Rack-mountable - 2U

Total Storage Capacity 0 GB

Installed Devices / Modules Qty 0 (installed) / 12 (max)

Width 48.2 cm

Depth 56.2 cm

Height 8.83 cm

Weight 13.73 kg ()

Processor / Memory

Processors Installed 1 x AMD Ryzen 7 3700X 3.6 GHz

Number of Cores 8-core

Max Supported Qty 1

Max Turbo Speed 4.4 GHz

RAM 32 GB (installed) / 128 GB (supported) - DDR4

Flash Memory Installed 5 GB

Storage Controller

Type RAID

Interface Type SATA 6Gb/s

RAID Level RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, JBOD, RAID 5 hot spare, RAID 6 hot spare, RAID 60, RAID 10 hot spare, RAID TP

Networking

Data Link Protocol 1GbE, 10GbE, 10 GigE optical

Remote Management Protocol SNMP 2, SNMP 3

Network Services Compatibility Microsoft Active Directory (AD), Apple Bonjour Protocol, File Level Security (ACLs), Microsoft CIFS, FTP, Server Message Block (SMB), Apple File Protocol (AFP)

Features ALERT notification, LDAP support, VLAN support, WOL, Syslog support, ACL support, iTunes server, Jumbo Frames support, DLNA Media Server, Apple Time Machine compatible, VPN Server, Apple AirPlay, anti-virus protection, Link Aggregation, Google Drive support, Chromecast support, port trunking, Microsoft Azure support, Amazon S3 support, Amazon Glacier suport, Qsirch, deduplication (volume and LUN), snapshot (folder and LUN), compression (volume and LUN)

Encryption Algorithm AES-NI

Compliant Standards UPnP

Expansion / Connectivity

Expansion Bays 12 (total) / 12 (free) x hot-swap - 2.5" / 3.5"

Expansion Slots 2 (total) / 1 (free) x PCI Express 3.0 x8 ¦ 2 (total) / 2 (free) x PCI Express 3.0 x4

Interfaces 2 x Ethernet 1000Base-T - RJ-45 ¦ 1 x USB 3.1 Gen 2 - Type A ¦ 4 x USB 3.0 - Type A ¦ 1 x USB 3.1 Gen 2 - Type C ¦ 2 x Ethernet 10Gb - SFP+ ¦ 2 x Ethernet 10Base-T - RJ-45

Miscellaneous

Cables Included 2 x network cable ¦ 2 x 10GBase-T cable

Features Audible alarm, built-in 2 cooling fans, dual boot

Included Accessories 48 x flat head screws (for 3.5" HDD), 36 x flat head screws (for 2.5" HDD), 2 x power cables

Power

Power Device Internal power supply

Installed Qty 2

Max Supported Qty 2

Power Redundancy Yes

Power Redundancy Scheme 1+1

Voltage Required AC 120/230 V

Power Consumption Operational 106.66 Watt

Power Provided 300 Watt

Software / System Requirements

Storage Operating System QNAP QTS hero

Dimensions & Weight (Shipping)

Shipping Weight 16 kg

Environmental Parameters

Min Operating Temperature 0 °C

Max Operating Temperature 40 °C

Humidity Range Operating 5 - 95% (non-condensing)

Sound Emission 37.2 dBA
