BACK-UPS 1200VA 230V AVR 6 IEC OUTLETS
Checking delivery…
Product details
- UPS
- tower, IEC C13 outlets, AVR
- AC 230 V
- 650 Watt
Payment options available at checkout
Main features
- Schneider Electric Back-UPS BXS series BXS1200MI
- UPS
- tower, IEC C13 outlets, AVR
- AC 230 V
- 650 Watt
- 1200 VA
- 1-phase
- 9 Ah
- output connectors: 6
- black
Overview
Schneider Electric Back-UPS BXS series BXS1200MI - UPS - tower, IEC C13 outlets, AVR - 650 Watt - 1200 VA
Product Description
Schneider Electric Back-UPS BXS series BXS1200MI - UPS - tower, IEC C13 outlets, AVR - 650 Watt - 1200 VA
Device Type
UPS - external
Weight
7.6 kg
Input Wiring
1-phase
Input Voltage
AC 230 V
Output Voltage
AC 230 V
Power Capacity
650 Watt / 1200 VA
Input Connectors
1 x power IEC 60320 C14
Output connectors
6 x power IEC 60320 C13
Battery
Lead Acid - 9 Ah
Run Time (Up To)
61 sec at full load
Colour
Black
Dimensions (WxDxH)
14 cm x 39 cm x 19 cm
Manufacturer Warranty
2-year warranty
General
Device Type
UPS - external
Colour
Black
Power Device
UPS Technology
Line interactive
Input Voltage
AC 230 V
Input Voltage Range
AC 220 - 240 V
Frequency Provided
50/60 Hz ± 1Hz
Input Wiring
1-phase
Frequency Required
50/60 Hz ± 5Hz
Input Connectors
1 x power IEC 60320 C14
Power Output Connectors Details
6 x power IEC 60320 C13
Output Voltage
AC 230 V 50/60 Hz
Power Capacity
650 Watt / 1200 VA
Dataline Surge Protection
Network - RJ-45 - 1 input line / 1 output line
Output Waveform
Stepped approximation to a sinewave
Surge Energy Rating
273 Joules
Circuit Protection
Circuit breaker
Efficiency
97.3% at 100% Load, 96.6% at 75% Load, 91% at 25% Load, 95.2% at 50% Load
Battery
Technology
Lead Acid
Voltage Provided
12 V
Capacity
9 Ah
Run Time (Up To)
405 sec at 50% load ¦ 61 sec at full load
Recharge Time
8 hours
Transfer Time
10 ms
Expansion / Connectivity
Interfaces
1 x USB
Miscellaneous
Cables Included
Power cable - external - 1.22 m
Equipment Protection Value
50000 Euros
Features
LED display, Automatic Voltage Regulation (AVR)
Compliant Standards
CB, RoHS, REACH, IP20, EN IEC 62040-1:2019 + A11:2021
Manufacturer Warranty
Service & Support
Limited warranty - replace or repair - 2 years
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
0 - 95% RH (non-condensing)
Sound Emission
40 dBA
Dimensions & Weight
Width
14 cm
Depth
39 cm
Height
19 cm
Weight
7.6 kg
Dimensions & Weight (Shipping)
Shipping Width
23.5 cm
Shipping Depth
49.5 cm
Shipping Height
30.5 cm
Shipping Weight
9.1 kg
