General
Product Type
LED-backlit LCD flat panel display
Power Consumption Operational
177 Watt
Diagonal Class
86"
Commercial Use
Yes - interactive
Combined With
Built-in interactive whiteboard, touchscreen (multi touch), 6-microphone array, RFID NFC reader/writer CCID
Series
MX Pro (V4) Series with iQ
Platform
Android
Operating System
Android OS 11
TV Tuner
No tuner
TV Tuner Presence
No
Sensors
Ambient light sensor (ALS), NFC sensor, Infrared (IR)
Video Interface
HDMI
HDMI Ports Qty
3 ports
PC Interface
VGA (HD-15), USB-C
Protection
Bonded glass
Width
198.2 cm
Depth
8.9 cm
Height
119.9 cm
Weight
68 kg
Enclosure Colour
White
Display
Resolution
3840 x 2160
Display Format
4K UHD (2160p)
Image Aspect Ratio
16:9
Frame Rate & Enhancement Technology
60 Hz Refresh Rate
LCD Backlight Technology
LED backlight
Coating
Anti-glare, heat-tempered glass
Brightness
400 cd/m²
Viewing Angle
178 degrees
Touchpoints Qty
20
Response Time
8 ms
Display Menu Language
Danish, Hungarian, Czech, Basque, Slovenian, Slovak, Chinese (traditional), Chinese (simplified), Vietnamese, Ukrainian, Galician, English, German, French, Italian, Norwegian, Portuguese, Polish, Finnish, Swedish, Russian, Spanish, Dutch, Greek, Latvian, Lithuanian, Estonian, Romanian, Catalan, Japanese, Korean, Valencian, Welsh
Backlight Life
50,000 hour(s)
Features
Object Awareness, Over-the-Air Update (OTA), OPS Slot, Silktouch, simultaneous tool differentiation, +/- 1mm touch accuracy, HyPr Touch (Hybrid Precision Touch) technology with Advanced IR, screen sharing, OPS-C support
Stands & Mounts
Flat Panel Mount Interface
800 x 600 mm
VESA Compatibility
Yes
Media Player
Supported Memory Cards
microSD
USB Port
Yes
USB Ports Qty
11
Configuration
8 GB - 32 GB
Remote Control
Type
Remote control
Battery Form Factor
AAA type
Battery Included
Yes
Battery Included Qty
2
Battery Required Qty
2
Audio System
Speaker System
2 speakers
Output Power / Total
40 Watt
Features
Built-in 6 array microphones
Speakers
2 x main channel speaker - 20 Watt
Network & Internet Multimedia
Functionality
WEB browsing
Connectivity
Wi-Fi, LAN, Bluetooth, NFC
LAN Protocol
Gigabit Ethernet
Wi-Fi Protocol
802.11b, 802.11g, 802.11n, 802.11a, 802.11ac, 802.11ax
Bluetooth Version
Bluetooth 5.2
Encryption
WPA2, WEP, WPA3
Connections
Connector Type
2 x HDMI input - rear ¦ HDMI input - front ¦ VGA input - rear ¦ Audio line-out - rear ¦ RS-232 input - rear ¦ USB-C with 65W Power Delivery - rear ¦ Gigabit LAN input - rear ¦ USB-C with 15W Power Delivery - front ¦ USB 2.0 - rear ¦ 2 x USB 3.2 - front ¦ 2 x USB 3.2 - rear ¦ USB 3.2 Gen 1 - front ¦ 3 x USB 3.2 Gen 1 - rear ¦ HDMI output - rear ¦ Audio line-out - rear ¦ SPDIF output - rear ¦ Gigabit LAN output - rear
Miscellaneous
Included Accessories
Power cable, 2 touch pens, SMART Meeting Pro software (10 personal licences), SMART Ink, SMART Product Drivers, SMART Remote Management, 2 SMART ID cards (for NFC sign in), 3 x Wi-Fi aerials
Cables Included
USB type A to USB type B cable - 5 m
Compliant Standards
UL, CB, FCC, ISO 14443 type A, RoHS, WEEE, ISO 14443 type B, ISO 15693, REACH, LVD, RCM, TSCA, CP65, CCID, HDCP 1.4, ISED, RED, CONEG, IEEE 802.1x, HDCP 2.3, POP, UKCA, EMCD
Sustainability Information
ENERGY STAR Certified
Yes
Power
Power Device
Power supply
Input Voltage
AC 100-240 V (50/60 Hz)
Power Consumption Stand by
0.5 Watt
Dimensions & Weight (Shipping)
Width (Shipping)
216.5 cm
Depth (Shipping)
16 cm
Height (Shipping)
144.5 cm
Weight (Shipping)
94 kg
Environmental Parameters
Min Operating Temperature
5 °C
Max Operating Temperature
35 °C
Humidity Range Operating
5 - 80% RH (non-condensing)
