General
Product Type
OLED TV - Smart TV
Energy Label QR Code URL
Https://eprel.ec.europa.eu/qr/1815117
Energy Class
Class E
Energy Class (HDR)
Class G
Power Consumption Operational
619 Watt
Power Consumption SDR (On mode)
107 kWh/1000h
Power Consumption HDR (On mode)
142 kWh/1000h
Diagonal Class
77"
Diagonal Size
76.7"
Commercial Use
Yes - digital signage
Model Year
2024
Platform
Google TV
Operating System
Android OS 12
HDR Capable
Yes
HDR Format
HDR10, Dolby Vision
HDR Technology
Hybrid Log-Gamma (HLG)
Video Processor
XR
TV Tuner
1x analogue, 2x digital
TV Tuner Presence
Yes
Sensors
Temperature sensor, light sensor
Video Interface
HDMI
HDMI Ports Qty
4 ports
Modes
Auto Genre Picture Mode, auto power save mode, Standard mode, Vivid mode, Cinema mode, professional mode, photo mode, Calm mode, Dolby Vision bright mode, Dolby Vision dark mode, Dolby Vision vivid mode, Dolby Vision Game, FPS Game mode, RTS Game mode, Auto Low Latency Mode (ALLM), Film Mode
Picture Enhancements
IMAX Enhanced, XR Clear Image, Auto HDR Tone Mapping, Live Color, Netflix Calibrated Mode, Dynamic Contrast Enhancer, XR Contrast Booster 15, Crystal Clear, CineMotion
Design
Seamless Edge
Dimensions
Without stand
Width
171.3 cm
Depth
3.8 cm
Height
101.2 cm
Weight
32.3 kg
Enclosure Colour
Dark silver, vibration finish
Display
Resolution
3840 x 2160
Display Format
4K UHD (2160p)
Image Aspect Ratio
16:9
Frame Rate & Enhancement Technology
Variable Refresh Rate (VRR), XR OLED Motion, 120 Hz Refresh Rate
24p Technology
24p True Cinema
LCD Backlight Technology
Frame blinking
Viewing Angle
178 degrees
Viewing Angle (Vertical)
178 degrees
Display Menu Language
Multilingual
Features
XR Triluminos Pro Display, PlayStation Remote Play, Apple AirPlay support, Chromecast built-in, ECO Dashboard, sleep timer, Dynamic Backlight Control, text magnification, Accessibility shortcut, Audio Description (AD), CalMAN auto calibration support, SORPLAS, UVC/UAC support, screen reader
Stands & Mounts
Stand
Included
Stand Design
Tabletop
Stand Colour
Dark silver
Stand Features
4-way position, underlay stand
Flat Panel Mount Interface
300 x 300 mm
VESA Compatibility
Yes
TV Tuner
Analogue TV Tuner
PAL/SECAM
Conditional Access
Common Interface Plus (CI+) slot
Digital TV Tuner
Digital TV Tuner
DVB-C, DVB-S, DVB-S2, DVB-T, DVB-T2
HDTV Tuner
Yes
Video Features
Analogue Video Input Signals
PAL, SECAM
Teletext
Yes
Teletext Memory
1000 pages
Electronic Programme Guide
Digital EPG
Parental Channel Lock
Yes
Media Player
Supported Video Formats
MPEG-1, MPEG-2, MPEG-4, Motion-JPEG, Xvid, WMV, ASF, AVI, MKV, MOV, AVCHD, AVC, 3GPP, VC-1, WebM, HEVC, VP9, VP8, XAVCS, HDV
Supported Audio Formats
MP3, WMA, WAV, AAC, FLAC (Free Lossless Audio Codec), LPCM, ASF, MP4, OGG, AC4
Supported Pictures Formats
JPEG, HEIF
USB Port
Yes
USB Ports Qty
2
Configuration
32 GB
Remote Control
Type
Remote control
Remote Control Model
Sony RMF-TX920U+RMT-TX450E
Battery Form Factor
AAA / LR03 / R03
Battery Included
Yes
Features
Voice control
Audio System
Digital Audio Format
Dolby Atmos, DTS:X, Dolby Audio, DTS-HD Master Audio output, DTS-HD High-Resolution Audio digital output, DTS Express
Surround Mode
Yes
Sound Effects
3D Surround Upscaling, DTS Digital Surround, Headphone 3D surround ready, Auto Surround, S-FORCE Front Surround Sound
Speaker System
2 tweeters, 2 speakers, subwoofer
Output Power / Total
50 Watt
Features
Acoustic Surface Audio+ technology, Voice Zoom 3, Crystal Clear, Enhanced Audio Return Channel (eARC), Audio Return Channel (ARC), 360 Spatial Sound Mapping, Room Compensation, User Position Compensation, Acoustic Center Sync, Sound Positioning Tweeter, Bass Reflex Speaker System, built-in microphone switch, Simultaneous Audio, Acoustic Auto Calibration, S-Master Digital Amplifier, Clear Phase Speaker, Vertical Surround Engine
Speakers
2 x speaker - 10 Watt ¦ 2 x tweeter - 10 Watt ¦ 1 x subwoofer - 10 Watt
Driver Details
Speaker: 2 x full-range driver ¦ Tweeter: 2 ¦ Subwoofer: 1
Network & Internet Multimedia
Functionality
WEB browsing, Internet video playback
Connectivity
Wi-Fi, LAN, Bluetooth
LAN Protocol
Ethernet
Wi-Fi Protocol
802.11b, 802.11g, 802.11n, 802.11a, 802.11ac, 802.11ax
Bluetooth Version
Bluetooth 5.3
Connect & Share
Bluetooth Human Interface Device (HID), Home Network Client, Home Network Renderer
Internet Streaming Services
Netflix, Prime Video, YouTube, Bravia Core, Voice Search
Supported Consumer Electronics Control (CEC)
BRAVIA Sync Function
Application Store
Google Play
Connections
Connector Type
4 x HDMI input - side ¦ 2 x USB - side ¦ LAN - side ¦ Digital audio output - side
Internet of Things (IoT)
Internet of Things (IoT) Compatible
Yes
Platform
Apple HomeKit
Miscellaneous
Compliant Standards
HDCP 2.3, CEC, Mercury-free
Power
Power Device
Power supply
Input Voltage
AC 220 - 240 V (50 Hz)
Power Consumption Stand by
0.5 Watt
Auto On/Off
Yes
Features
On/off timer
Manufacturer Warranty
Service & Support
Limited warranty - advanced exchange programme - 3 years
Bundled Services
3 years PrimeSupport
Dimensions & Weight Details
Dimensions & Weight Details
Panel without stand - 171.3 cm x 3.8 cm x 101.2 cm x 32.3 kg ¦ Panel with stand and soundbar - 171.3 cm x 40.5 cm x 106.6 cm x 34 kg ¦ Panel with stand (narrow position) - 171.3 cm x 40.5 cm x 101.2 cm x 32.3 kg ¦ Dimensions between support feet - 125.8 cm
Dimensions & Weight (Shipping)
Width (Shipping)
191.2 cm
Depth (Shipping)
19.1 cm
Height (Shipping)
112.2 cm
Weight (Shipping)
45 kg
