General
Device Type
Wireless router - 5-port switch (integrated)
Enclosure Type
Desktop
Connectivity Technology
Wireless, wired
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax
Frequency Band
2.4 GHz / 5 GHz
Performance
Maximum data rate (2.4 GHz): 574 Mbps ¦ Maximum data rate (5 GHz): 4804 Mbps
Capacity
Streams: 6
Network / Transport Protocol
PPTP, L2TP, PPPoE, DHCP, DDNS, IPv4, IPv6
Routing Protocol
IGMP, static IP routing
Remote Management Protocol
HTTP, DHCP
Encryption Algorithm
WPA, WPA2, WPA-Enterprise, WPA2-Enterprise, WPS, WPA3
Wi-Fi Rating
AX5400
Features
IGMP snooping, SPI, DFS support, parental control, Access Point operational mode, ACL support, QoS, virtual server support, WPS, DHCP server, Samba support, FTP server, port forwarding, UPnP Media Server, reset button, Apple Time Machine compatible, port triggering, dynamic IP mode, IP-MAC binding, DHCP client, 4T4R MIMO technology, tagged VLAN, IGMP proxy, beamforming technology, Static Link Aggregation, LED on/off button, Airtime Fairness, 4x4 MU-MIMO technology, Smart Roaming, DMZ support, bridge mode, OpenVPN client, IPTV support, 8K HD video streaming, WPS button, OneMesh support, 160MHz bandwidth support, auto firmware update, TP-Link HomeShield, Wi-Fi on/off button
Compliant Standards
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.1x, IEEE 802.11n, UPnP, IEEE 802.11ac, IEEE 802.11ax, Wi-Fi CERTIFIED 6, FCC, RoHS
Processor
Qualcomm 1 GHz
