General
Device Type
Switch - 8 ports - smart
Enclosure Type
Desktop
Subtype
Gigabit Ethernet
Ports
8 x 10/100/1000 + 2 x SFP
Power Over Ethernet (PoE)
PoE
PoE Budget
58 W
Performance
Bandwidth: 20 Gbps ¦ Forwarding performance: 14.9 Mpps
Capacity
Active VLANs: 512
MAC Address Table Size
8K entries
Jumbo Frame Support
9216 bytes
Routing Protocol
IGMPv2, IGMP, IGMPv3
Remote Management Protocol
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, SNMP 2c, HTTP, SSH, SSH-2, CLI
Encryption Algorithm
TLS 1.0, SSL 3.0, SSL 2.0
Authentication Method
Secure Shell (SSH), Secure Shell v.2 (SSH2)
Features
Flow control, auto-negotiation, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, port mirroring, manageable, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, firmware upgradable, SNTP support, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Virtual Cable Test (VCT) technology, Multiple Spanning Tree Protocol (MSTP) support, Quality of Service (QoS), SSH support, fanless, Management Information Base (MIB), Class of Service (CoS), Loopback, DiffServ Code Point (DSCP) support
Compliant Standards
IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s
Status Indicators
Port transmission speed, power, system, PoE, link/activity
